Integrated Silicon Solution, Inc. — 1-800-379-4774
Rev.
A
0
3/22/06
7
ISSI
IS43R16320A
Capacitance
Parameter
Symbol
Min.
Max.
Units
Notes
Input Capacitance: CK, CK
CI
1
2.0
3.0
pF
1
Delta Input Capacitance: CK, CK
delta CI
1
0.25
pF
1
Input Capacitance: All other input-only pins (except DM)
CI
2
2.0
3.0
pF
1
Delta Input Capacitance: All other input-only pins (except DM)
delta CI
2
0.5
pF
1
Input/Output Capacitance: DQ, DQS, DM
C
IO
4.0
5.0
pF
1, 2
Delta Input/Output Capacitance: DQ, DQS, DM
delta C
IO
0.5
pF
1
1. V
DDQ
= V
DD
= 2.5V ±
0.2V (minimum range to maximum range), f = 100MHz, T
A
= 25
°
C, VO
DC
= V
DDQ/2
, VO
Peak -Peak
= 0.2V.
2. Although DM is an input-only pin, the input capacitance of this pin must model the input capacitance of the DQ and DQS pins. This is
required to match input propagation times of DQ, DQS and DM in the system.
DC Electrical Characteristics and Operating Conditions
(0°C < T
A
<
70
o
C; V
DDQ
= V
DD
=
+
2.5V
±
0.2V (DDR333); see AC Characteristics)
Symbol
Parameter
Min
Max
Units
Notes
V
DD
Supply Voltage DDR333
2.3
2.7
V
1
V
DDQ
I/O Supply Voltage DDR333
2.3
2.7
V
1
V
1, 2
V
SS
, V
SSQ
Supply Voltage
I/O Supply Voltage
0
0
V
V
REF
I/O Reference Voltage
0.49 x V
DDQ
0.51 x V
DDQ
V
TT
I/O Termination Voltage (System)
V
REF
- 0.04
V
REF
+ 0.04
V
1, 3
V
IH(DC)
Input High (Logic1) Voltage
V
REF
+ 0.15
V
DDQ
+ 0.3
V
1
V
IL(DC)
Input Low (Logic0) Voltage
-0.3
V
REF
- 0.15
V
1
V
IN(DC)
Input Voltage Level, CK and CK Inputs
-0.3
V
DDQ
+ 0.3
V
1
V
ID(DC)
Input Differential Voltage, CK and CK Inputs
0.30
V
DDQ
+ 0.6
V
1, 4
V
IX(DC)
Input Crossing Point Voltage, CK and CK Inputs
0.30
V
DDQ
+ 0.6
V
1, 4
VI
Ratio
V-I Matching Pullup Current to Pulldown Current Ratio
0.71
1.4
2
-2
-5
5
5
I
I
Input Leakage Curr ent
Any input 0V < V
IN
<
V
DD
; (All other pins not under test = 0V)
A
1
I
OZ
Output Leakage Current
(DQs are disabled; 0V < V
out
< V
DDQ
A
1
1. Inputs are not recognized as valid until V
REF
stabilizes.
2. V
REF
is expected to be equal to 0.5 V
DDQ
of the transmitting device, and to track variations in the DC level of the same. Peak-to-peak
noise on V
REF
may not exceed ± 2% of the DC value.
3. V
TT
is not applied directly to the device. V
TT
is a system supply for signal termination resistors, is expected to be set equal to V
REF
, and
must track variations in the DC level of V
REF
.
4. V
ID
is the magnitude of the difference between the input level on CK and the input level on CK.
5. The ratio of the pullup current to the pulldown current is specified for the same temperature and voltage, over the entire temperature and
voltage range, for device drain to source voltages for 0.25 volts to 1.0 volts. For a given output, it represents the maximum difference
between pullup and pulldown drivers due to process variation.
μ
μ
