IS80LV52
IS80LV32
Integrated Silicon Solution, Inc. — 1-800-379-4774
ADVANCE INFORMATION
MC019-0A
10/01/98
13
ISSI
TMOD:
Timer/Counter Mode Control Register.
Not Bit Addressable.
Timer 1
GATE C/
T
M1 M0
Timer 0
GATE
C/
T
M1 M0
GATE When TRx (in TCON) is set and GATE=1, TIMER/
COUNTERx will run only while INTx pin is high
(hardware control). When GATE=0, TIMER/
COUNTERx will run only while TRx=1 (software
control).
C/
T
Timer or Counter selector. Cleared for Timer
operation (input from internal system clock). Set
for Counter operation (input from Tx input pin).
M1
Mode selector bit.
(1)
M0
Mode selector bit.
(1)
Note 1:
M1
M0
Operating mode
0
0
Mode 0. (13-bit Timer)
0
1
Mode 1. (16-bit Timer/Counter)
1
0
Mode 2. (8-bit auto-load Timer/Counter)
1
1
Mode 3. (Splits Timer 0 into TL0 and
TH0. TL0 is an 8-bit Timer/Counter con-
troller by the standard Timer 0 control
bits. TH0 is an 8-bit Timer and is con-
trolled by Timer 1 control bits.)
1
1
Mode 3. (Timer/Counter 1 stopped).
SCON:
Serial Port Control Register. Bit Addressable.
7
SM0 SM1
6
5
4
3
2
1
TI
0
RI
SM2
REN
TB8
RB8
Register Description:
SM0
SCON.7
SM1
SCON.6
SM2
SCON.5
Serial port mode specifier.
(1)
Serial port mode specifier.
(1)
Enable the multiprocessor com-
munication feature in mode 2 and 3. In
mode 2 or 3, if SM2 is set to 1 then RI
will not be activated if the received 9th
data bit (RB8) is 0. In mode 1, if
SM2=1 then RI will not be activated if
valid stop bit was not received. In
mode 0, SM2 should be 0.
Set/Cleared by software to Enable/
Disable reception.
The 9th bit that will be transmitted in
mode 2 and 3. Set/Cleared by
software.
In modes 2 and 3, RB8 is the 9th data
bit that was received. In mode 1, if
SM2=0, RB8 is the stop bit that was
received. In mode 0, RB8 is not used.
Transmit interrupt flag. Set by
hardware at the end of the 8th bit time
in mode 0, or at the beginning of the
stop bit in the other modes. Must be
cleared by software.
Receive interrupt flag. Set by hardware
at the end of the 8th bit time in mode
0, or halfway through the stop bit time
in the other modes (except see SM2).
Must be cleared by software.
REN SCON.4
TB8
SCON.3
RB8
SCON.2
TI
SCON.1
RI
SCON.0
Note:
SM0
SM1 MODE
Description
Baud rate
0
0
0
Shift register
Fosc/12
0
1
1
8-bit UART
Variable
1
0
2
9-bit UART
Fosc/64 or
Fosc/32
1
1
3
9-bit UART
Variable
