3
FN6111.2
November 3, 2006
Absolute Maximum Ratings
Thermal Information
V+ to GND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3 to 4.7V
Input Voltages
NO, NC, IN (Note 2) . . . . . . . . . . . . . . . . . . . -0.3 to ((V+) + 0.3V)
Output Voltages
COM (Note 2) . . . . . . . . . . . . . . . . . . . . . . . . -0.3 to ((V+) + 0.3V)
Continuous Current NO, NC, or COM . . . . . . . . . . . . . . . . .
±
300mA
Peak Current NO, NC, or COM
(Pulsed 1ms, 10% Duty Cycle, Max) . . . . . . . . . . . . . . . .
±
500mA
ESD Rating:
HBM COM
X
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .>9kV
HBM NO
X
, NC
X
, IN
X
, V+, GND . . . . . . . . . . . . . . . . . . . . . . .>4kV
MM COM
X
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .>500V
MM NO
X
, NC
X
, IN
X
, V+, GND . . . . . . . . . . . . . . . . . . . . . . .>300V
CDM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .>1kV
Thermal Resistance (Typical, Note 3)
TQFN and QFN Package (Note 4). . . . . . . . . . . . . .
TSSOP Package (Note 3) . . . . . . . . . . . . . . . . . . . .
Maximum Junction Temperature (Plastic Package). . . . . . . +150°C
Maximum Storage Temperature Range . . . . . . . . . . . -65°C to +150°C
Maximum Lead Temperature (Soldering 10s) . . . . . . . . . . . +300°C
(Lead Tips Only)
θ
JA
(°C/W)
70
150
Operating Conditions
Temperature Range
ISL8499IX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40°C to +85°C
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
NOTES:
2. Signals on NC, NO, IN, or COM exceeding V+ or GND are clamped by internal diodes. Limit forward diode current to maximum current ratings.
3.
θ
JA
is measured with the component mounted on a high effective thermal conductivity test board in free air. See Tech Brief TB379 for details.
4.
θ
JA
is measured in free air with the component mounted on a high effective thermal conductivity test board with “direct attach” features. See
Tech Brief TB379.
Electrical Specifications - 4.3V Supply
Test Conditions: V+ = +3.9V to +4.5V, GND = 0V, V
INH
= 1.6V, V
INL
= 0.5V (Notes 5, 7),
Unless Otherwise Specified
PARAMETER
TEST CONDITIONS
TEMP
(°C)
(NOTE 6)
MIN
TYP
(NOTE 6)
MAX
UNITS
ANALOG SWITCH CHARACTERISTICS
Analog Signal Range, V
ANALOG
ON Resistance,
r
ON
Full
0
-
V+
V
V+ = 3.9V, I
COM
= 100mA, V
NO
or V
NC
= 0V to V+,
(See Figure 5)
25
-
0.25
-
Ω
Full
-
0.28
-
Ω
r
ON
Matching Between Channels,
Δ
ON
V+ = 3.9V, I
COM
= 100mA, V
NO
or V
NC
= Voltage at
max
r
ON,
(Note 10)
25
-
0.04
-
Ω
Full
-
0.05
-
Ω
r
ON
Flatness, R
FLAT(ON)
V+ = 3.9V, I
COM
= 100mA, V
NO
or V
NC
= 0V to V+,
(Note 8)
25
-
0.05
-
Ω
Full
-
0.05
-
Ω
NO or NC OFF Leakage Current,
I
NO(OFF)
or I
NC(OFF)
V+ = 4.5V, V
COM
= 0.3V, 3V, V
NO
or V
NC
= 3V, 0.3V
25
-50
-
50
nA
Full
-150
-
150
nA
COM ON Leakage Current,
I
COM(ON)
V
+
= 4.5V, V
COM
= 0.3V, 3V, or V
NO
or V
NC
= 0.3V, 3V,
or Floating
25
-50
-
50
nA
Full
-150
-
150
nA
DYNAMIC CHARACTERISTICS
Turn-ON Time, t
ON
V+ = 3.9V, V
NO
or V
NC
= 3.0V, R
L
= 50
Ω
, C
L
= 35pF,
(See Figure 1, Note 9)
25
-
15
25
ns
Full
-
-
30
ns
Turn-OFF Time, t
OFF
V+ = 3.9V, V
NO
or V
NC
= 3.0V, R
L
= 50
Ω
, C
L
= 35pF,
(See Figure 1, Note 9)
25
-
13
23
ns
Full
-
-
28
ns
Break-Before-Make Time Delay, t
D
V+ = 4.5V, V
NO
or V
NC
= 3.0V, R
L
= 50
Ω
, C
L
= 35pF,
(See Figure 3, Note 9)
Full
2
3
-
ns
Charge Injection, Q
C
L
= 1.0nF, V
G
= 0V, R
G
= 0
Ω, (
See Figure 2)
25
-
-120
-
pC
OFF Isolation
R
L
= 50
Ω
, C
L
= 5pF, f = 100kHz, V
COM
= 1V
RMS
,
(See Figure 4)
25
-
68
-
dB
Crosstalk (Channel-to-Channel)
R
L
= 50
Ω
, C
L
= 5pF, f = 100kHz, V
COM
= 1V
RMS
,
(See Figure 6)
25
-
-98
-
dB
ISL8499
