Philips Semiconductors
ISP1104
Advanced USB transceiver
Product data
Rev. 02 — 14 October 2003
5 of 19
9397 750 11229
Koninklijke Philips Electronics N.V. 2003. All rights reserved.
7.
Functional description
7.1 Function selection
[1]
Signal levels on pins D
+
and D
are determined by other USB devices and external pull-up or
pull-down resistors.
In the suspend mode (pin SUSPND = HIGH), the differential receiver is inactive and the output RCV is
always LOW. Out-of-suspend (K) signalling is detected via the single-ended receivers VP and VM.
[2]
7.2 Operating functions
[1]
[2]
VP = VM = H indicates the sharing mode (V
CC(5.0)
is disconnected).
RCV* denotes the signal level on output RCV just before the SE0 state occurs. This level is stable
during the SE0 period.
Table 3:
SUSPND OE
L
Function table
D
+
and D
driving/
receiving
receiving
[1]
driving
RCV
active
VP/VM
active
Function
normal driving
(differential receiver active)
receiving
driving during ‘suspend’
(differential receiver inactive)
low-power state
L
L
H
H
L
active
inactive
[2]
active
active
H
H
high-Z
[1]
inactive
[2]
active
Table 4:
Driving function using single-ended input data interface (pin OE = L and
pin MODE = L)
VO
Data
L
differential logic 0
H
differential logic 1
L
SE0
H
SE0
FSE0
L
L
H
H
Table 5:
Driving function using differential input data interface (pin OE = L and
pin MODE = H)
VPO
Data
L
SE0
H
differential logic 1
L
differential logic 0
H
illegal state
VMO
L
L
H
H
Table 6:
D
+
and D
differential logic 0
differential logic 1
SE0
Receiving function (pin OE = H)
RCV
L
H
RCV*
[2]
VP
[1]
L
H
L
VM
[1]
H
L
L
