K6X8016C3B Family
Revision 1.0
September 2003
4
CMOS SRAM
RECOMMENDED DC OPERATING CONDITIONS
1)
Note:
1. Commercial Product: T
A
=0 to 70
°
C, otherwise specified.
Industrial Product: T
A
=-40 to 85
°
C, otherwise specified.
Automotive Product: T
A
=-40 to 125
°
C, otherwise specified.
2. Overshoot: V
CC
+3.0V in case of pulse width
≤
30ns.
3. Undershoot: -3.0V in case of pulse width
≤
30ns.
4. Overshoot and undershoot are sampled, not 100% tested.
Item
Symbol
Min
Typ
Max
Unit
Supply voltage
Vcc
4.5
5.0
5.5
V
Ground
Vss
0
0
0
V
Input high voltage
V
IH
2.2
-
Vcc+0.5
2)
0.8
V
Input low voltage
V
IL
-0.5
3)
-
V
CAPACITANCE
1)
(f=1MHz, T
A
=25
°
C)
1. Capacitance is sampled, not 100% tested
Item
Symbol
Test Condition
Min
Max
Unit
Input capacitance
C
IN
V
IN
=0V
-
8
pF
Input/Output capacitance
C
IO
V
IO
=0V
-
10
pF
DC AND OPERATING CHARACTERISTICS
Item
Symbol
Test Conditions
Min
Typ
Max
Unit
Input leakage current
I
LI
V
IN
=Vss to Vcc
-1
-
1
μ
A
μ
A
Output leakage current
I
LO
CS=V
IH,
OE=V
IH
or WE=V
IL
, V
IO
=Vss to Vcc
-1
-
1
Operating power supply current
I
CC
I
IO
=0mA, CS=V
IL,
WE=V
IH
, V
IN
=V
IH
or V
IL
-
-
6
mA
Average operating current
I
CC1
Cycle time=1
μ
s, 100% duty, I
IO
=0mA, CS
≤
0.2V, V
IN
≤
0.2V or
V
IN
≥
V
CC
-0.2V
Cycle time=Min, I
IO
=0mA, 100% duty, CS=V
IL
, V
IN
=V
IL
or V
IH
-
-
7
mA
I
CC2
-
-
35
mA
Output low voltage
V
OL
I
OL
= 2.1mA
-
-
0.4
V
Output high voltage
V
OH
I
OH
= -1.0mA
2.4
-
-
V
Standby Current(TTL)
I
SB
CS=V
IH
, Other inputs=V
IH
or V
IL
-
-
0.4
mA
Standby Current(CMOS)
I
SB1
CS
≥
Vcc-0.2V, Other inputs=0~Vcc
K6X8016C3B-B
-
-
25
μ
A
K6X8016C3B-F
-
-
25
K6X8016C3B-Q
-
-
40
