No. 7135-19/24
LC75863E, 75863W
Sample Application Circuit 2
1/2 bias (for use with large panels)
To the controller
power supply
To the controller
From the
controller
Used with the
backlight controller
or other circuit.
(general-purpose
output ports)
Key matrix
(up to 30 keys)
L
10 k
≥
R
≥
1 k
C
≥
0.047
μ
F
+5.5 V
+5 V
VDD
S23
S5
P4/S4
P3/S3
P2/S2
P1/S1
COM3
(P1)
(P2)
(P3)
(P4)
(S24)
(S25)
COM1
COM2
OSC
DO
DI
CL
*
8
R
R
C
*
9
CE
VLCD1
VLCD2
VLCD
TEST
VSS
S
2
5
/
K
S
2
S
2
4
/
K
S
1
K
S
3
K
S
4
K
I
1
K
I
2
K
I
3
K
I
4
K
I
5
K
S
5
K
S
6
Note:
*
8.
Add a capacitor to the logic block power supply line so that the logic block power supply voltage V
DD
rise time when power is applied and the
logic block power supply voltage V
DD
fall time when power drops are both at least 1 ms, as the LC75863E/W is reset by the VDET.
The DO pin, being an open-drain output, requires a pull-up resistor. Select a resistance (between 1 to 10 k
) appropriate for the capacitance of
the external wiring so that signal waveforms are not degraded.
*
9.
