6
LTC1142/LTC1142L/LTC1142HV
NC (Pins 7, 8):
No Connection.
PDRIVE 5 (Pin 9):
High Current Drive for Top P-Channel
MOSFET, 5V Section. Voltage swing at this pin is from V
IN5
to ground.
V
IN5
(Pin 10):
Supply pin, 5V section, must be closely
decoupled to 5V power ground Pin 18.
C
T5
(Pin 11):
External capacitor C
T5
from Pin 11 to ground
sets the operating frequency for the 5V section. (The actual
frequency is also dependent upon the input voltage.)
INTV
CC5
(Pin 12) :
Internal supply voltage for the 5V
section, nominally 3.3V, can be decoupled to signal ground,
Pin 17. Do not externally load this pin.
I
TH5
(Pin 13):
Gain Amplifier Decoupling Point, 5V Sec-
tion. The 5V section current comparator threshold in-
creases with the Pin 13 voltage.
SENSE
–
5 (Pin 14):
Connects to internal resistive divider
which sets the output voltage for the 5V section. Pin 14 is
also the (–) input for the current comparator on the
5V section.
SENSE
+
5 (Pin 15):
The (+) Input to the 5V Section Current
Comparator. A built-in offset between Pins 15 and 14 in
conjunction with R
SENSE5
sets the current trip threshold
for the 5V section.
SHDN5 (Pin 16):
When grounded, the 5V section operates
normally. Pulling Pin 16 high holds both MOSFETs off and
puts the 5V section in micropower shutdown mode.
Requires CMOS logic signal with t
r
, t
f
< 1
μ
s. Do not “float”
Pin 16.
SGND5 (Pin 17):
The 5V section small-signal ground must
be routed separately from other grounds to the (–) termi-
nal of the 5V section output capacitor.
PGND5 (Pin 18):
The 5V section driver power ground
connects to source of N-channel MOSFET and the (–)
terminal of the 5V section input capacitor.
NC (Pin 19):
No Connection.
NDRIVE 5 (Pin 20):
High Current Drive for Bottom
N-Channel MOSFET, 5V Section. Voltage swing at Pin 20
is from ground to V
IN5
.
NC (Pins 21, 22):
No Connection.
PDRIVE 3 (Pin 23):
High Current Drive for Top P-Channel
MOSFET, 3.3V Section. Voltage swing at this pin is from
V
IN3
to ground.
V
IN3
(Pin 24):
Supply pin, 3.3V section, must be closely
decoupled to 3.3V power ground, Pin 4.
C
T3
(Pin 25):
External capacitor C
T3
from Pin 25 to ground
sets the operating frequency for the 3.3V section. (The
actual frequency is also dependent upon the input voltage.)
INTV
CC3
(Pin 26):
Internal supply voltage for the 3.3V
section, nominally 3.3V, can be decoupled to signal ground,
Pin 3. Do not externally load this pin.
I
TH3
(Pin 27):
Gain Amplifier Decoupling Point, 3.3V
Section. The 3.3V section current comparator threshold
increases with the Pin 27 voltage.
SENSE
–
3 (Pin 28):
Connects to internal resistive divider
which sets the output voltage for the 3.3V section. Pin 28
is also the (–) input for the current comparator on the
3.3V section.
LTC1142HV-ADJ/LTC1142L-ADJ
SENSE
+
1 (Pin 1):
The (+) Input to the Section 1 Current
Comparator. A built-in offset between Pins 1 and 28 in
conjunction with R
SENSE1
sets the current trip threshold
for this section.
V
FB1
(Pin 2):
This pin serves as the feedback pin from an
external resistive divider used to set the output voltage for
section 1.
SHDN1 (Pin 3):
When grounded, the section 1 regulator
operates normally. Pulling Pin 3 high holds both MOSFETs
off and puts this section in micropower shutdown mode.
Requires CMOS logic signal with t
r
, t
f
< 1
μ
s. Do not “float”
Pin 3.
SGND1 (Pin 4):
The section 1 small-signal ground must
be routed separately from other grounds to the (–) termi-
nal of the section 1 output capacitor.
PGND1 (Pin 5):
The section 1 driver power ground con-
nects to source of N-channel MOSFET and the (–) terminal
of the section 1 input capacitor.
PU
