Electrical Characteristics
(Continued)
Note 9:
May exceed input supply voltage.
Note 10:
When used in dual-supply systems where the output terminal sees loads returned to a negative supply, the output voltage should be diode-clamped to
ground.
Note 11:
V
SHUTDOWN
≥
2V, V
IN
≤
30V, V
OUT
= 0, Feedback pin tied to V
TAP
.
Note 12:
Output or reference voltage temperature coefficient is defined as the worst case voltage change divided by the total temperature range.
Note 13:
Thermal regulation is defined as the change in output voltage at a time T after a change in power dissipation is applied, excluding load or line regulation
effects. Specifications are for a 50 mA load pulse at V
IN
= 30V (1.25W pulse) for T = 10ms.
Note 14:
Regulation is measured at constant junction temperature, using pulse testing with a low duty cycle. Changes in output voltage due to heating effects are
covered under the specification for thermal regulation.
Note 15:
Line regulation for the LP4951C is tested at 150C for I
L
= 1 mA. For I
L
= 100μA and T
J
= 125C, line regulation is guaranteed by design to 0.2%. See
Typical Performance Characteristics for line regulation versus temperature and load current.
Connection Diagrams
TO-92 Plastic Package (Z)
Surface-Mount Package (M)
20052802
Bottom View
20052826
Top View
Ordering Information
Package
Output Voltage
5.0V
LP4950CZ-5.0
LP4951CM
Temperature
TO-92 (Z)
M (M08A)
40C
<
T
J
<
125C
40C
<
T
J
<
125C
L
www.national.com
4
