參數資料
型號： LTC1069-7CS8#TR
廠商： Linear Technology
文件頁數： 4/10頁
文件大?。?/td> 0K
描述： IC FILTER LP 10TH ORD LIN 8SOIC
標準包裝： 2,500
濾波器類型： 線性相位，低通開關電容器
頻率 - 截止或中心： 200kHz
濾波器數： 1
濾波器階數： 8th
電源電壓： ±5V，5V
安裝類型： 表面貼裝
封裝/外殼： 8-SOIC（0.154"，3.90mm 寬）
供應商設備封裝： 8-SOIC
包裝： 帶卷 (TR)
LTC1069-7
3
10697fa
Note 1: Stresses beyond those listed under Absolute Maximum Ratings
may cause permanent damage to the device. Exposure to any Absolute
Maximum Rating condition for extended periods may affect device
reliability and lifetime.
Note 2: Phase Deviation = 1/2(Phase at 0Hz – Phase at fCUTOFF) – (Phase
at 0Hz – Phase at 0.5fCUTOFF)
Phase at 0Hz = 180° (guaranteed by design)
ELECTRICAL CHARACTERISTICS The l denotes specications which apply over the full operating
temperature range. fCUTOFF is the lter’s cutoff frequency and is equal to fCLK/25. The fCLK signal level is TTL or CMOS (max clock rise
or fall time ≤ 1μs), RL = 10k, TA = 25°C, unless otherwise specied. All AC gains are measured relative to the passband gain.
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Gain at 1.5fCUTOFF
VS = ± 5V, fCLK = 2.5MHz
fTEST = 150kHz, VIN = 1VRMS
–19
–16.5
–14
dB
VS = 4.75V, fCLK = 500kHz
fTEST = 30kHz, VIN = 0.5VRMS
–20
–18.1
–17
dB
Gain at 2.0fCUTOFF
VS = ± 5V, fCLK = 2.5MHz
fTEST = 200kHz, VIN = 1VRMS
–55
–43
–38
dB
VS = 4.75V, fCLK = 500kHz
fTEST = 40kHz, VIN = 0.5VRMS
–48
–41
–39
dB
Gain at 5.0fCUTOFF
VS = 4.75V, fCLK = 500kHz
fTEST = 100kHz, VIN = 0.5VRMS
–70
–59
–55
dB
Gain at fCUTOFF (160kHz)
VS = ±5V, fCLK = 4MHz
fTEST = 160kHz, VIN = 1VRMS
–2.1
dB
Phase at 0.5fCUTOFF
VS = ±5V, fCLK = 2.5MHz
fTEST = 50kHz
–35
–30.5
–25
Deg
Phase at fCUTOFF
VS = ±5V, fCLK = 2.5MHz
fTEST = 100kHz
–240
–235
–230
Deg
Passband Phase Deviation from
Linear Phase (Note 1)
VS = ±5V, fCLK = 500kHz
–3.0
Deg
Output DC Offset (Input at GND)
VS = ±5V, fCLK = 500kHz
VS = 4.75V, fCLK = 400kHz
50
25
125
mV
Output Voltage Swing
VS = ±5V, ISOURCE/ISINK ≤ 1mA, RL = 10k
VS = 4.75V, ISOURCE/ISINK ≤ 1mA, RL = 10k
l
±3.5
2.6
±4.0
3.6
V
VP-P
Power Supply Current
VS = ± 5V, fCLK = 500kHz
l
18
26
29
mA
VS = 4.75V, fCLK = 400kHz
l
13
15
16.5
mA
Example: An LTC1069-7 has Phase at 0.5fCUTOFF = – 30.5° and Phase at
fCUTOFF = –235°.
Passband Phase Deviation from Linear Phase
= 1/2[180° – (–235°)] – [(180° – (–30.5°)] = –3°
