LTC1700
16
PART NUMBER
LT1302
LT1304 Series
LT1307/LT1307B
LT1316
LT1317
LT1517-5
LT1610
LT1611
LT1613
LT1619
LTC1625
DESCRIPTION
Micropower Step-Up Regulator
2-Cell Micropower Step-Up Regulator
Single Cell Micropower Step-Up Regulator
Burst Mode Operation DC/DC with Programmable Current Limit
2-Cell Micropower Step-Up Regulator
Micropower, Regulated Charge Pump
1.7MHz Single Cell Micropower Step-Up Regulator
Inverting 1.4MHz Switching Regulator
1.4MHz Single Cell Micropower Regulator
Micropower Step-Up Regulator Controller
No R
SENSE
Synchronous Step-Down Controller
COMMENTS
5V/600mA from 2V, 2A Internal Switch, 200
μ
A I
Q
Low-Battery Detector Active in Shutdown
3.3V/75mA From 1V; 600kHz Fixed Frequency
1.5V Minimum V
IN
; Precise Control of Peak Switch Current
3.3V/200mA From Two Cells; 600kHz Fixed Frequency
3-Cells to 5V at 20mA, SOT-23 Package, 6
μ
A I
Q
30
μ
A IQ, MSOP Package, Internal Compensation
5V to -5V at 150mA, Low Output Noise
5-Lead SOT-23 Package
Drives External NMOS; 3.3V to 5V at up to 8A
Up to 97% Efficiency; 3.7V
≤
V
IN
≤
36V;
1.19V
≤
V
OUT
≤
V
IN
; I
OUT
up to 15A
5V
≤
V
IN
≤
30V; No R
SENSE
, Programmable Frequency
50kHz to 1MHz; 10-Lead MSOP
Minimum Board Area; Drives External NMOS
Up to 97% Efficiency; up to 3MHz Operation; No External
Diode; 0.85V Start-Up Voltage
LTC1871
Boost, Flyback and SEPIC Controller
LTC1872
LTC3401/LTC3402
SOT-23, 550kHz Step-Up Controller
Integrated 1A and 2A Synchronous Step-Up Regulators
Linear Technology Corporation
1630 McCarthy Blvd., Milpitas, CA 95035-7417
(408) 432-1900
G
FAX: (408) 434-0507
G
www.linear.com
LINEAR TECHNOLOGY CORPORATION 2000
1700f LT/TP 0801 2K PRINTED IN USA
RELATED PARTS
LTC1700 2.5V V
IN
3.3V/1.8A Output Regulator
SGND
I
TH
RUN/SS
V
FB
SYNC/MODE
SW
BG
PGND
TG
V
OUT
LTC1700
1
2
4
3
5
10
8
9
6
7
+
L1
2.2
μ
H
C3
22
μ
F
C1
10
μ
F
C4
220
μ
F
6.3V
300pF
470pF
470pF
33k
53.6k
30k
M2
M1
V
2.5V
V
3.3V/1.8A
1700 TA02
+
C2
68
μ
F
6.3V
C1: TAIYO YUDEN CERAMIC JMK316BJ106ML
C2: AVX TAJB68K006R
C3: TAIYO YUDEN CERAMIC JMK325BJ226M
C4: KEMET T520D227M006AS
L1: MURATA LQN6C
M1: Si9802
M2: Si9803
U
TYPICAL APPLICATIO
