100/120
參數資料
型號： MAX13450EAUD+
廠商： Maxim Integrated Products
文件頁數： 12/17頁
文件大?。?/td> 0K
描述： TXRX RS-485 14TSSOP
產品培訓模塊： Lead (SnPb) Finish for COTS
Obsolescence Mitigation Program
標準包裝： 96
類型： 收發器
驅動器/接收器數： 1/1
規程： RS485
電源電壓： 4.75 V ~ 5.25 V
安裝類型： 表面貼裝
封裝/外殼： 14-TSSOP （0.173"，4.40mm 寬）裸露焊盤
供應商設備封裝： 14-TSSOP-EP
包裝： 管件
RS-485 Transceivers with Integrated
100/120 Termination Resistors
MAX13450E/MAX13451E
4 ______________________________________________________________________________________
SWITCHING CHARACTERISTICS—SRL = HIGH
(VCC = +4.5V to +5.5V, VL = +1.62V to VCC, TA = TMIN to TMAX, unless otherwise noted. Typical values are at VCC = +5V,
VL = +1.8V and TA = +25NC.) (Note 2)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
DRIVER
Driver Propagation Delay
tDPLH
RDIFF = 54I, CL = 50pF, Figures 2 and 3
800
ns
tDPHL
800
Differential Driver Output Skew
|tDPLH - tDPHL|
tDSKEW
RDIFF = 54I, CL = 50pF, Figure 3
100
ns
Driver Differential Output Rise or
Fall Time
tHL
RDIFF = 54I, CL = 50pF, Figures 2 and 3
100
600
ns
tLH
100
600
Maximum Data Rate
DRMAX
500
kbps
Driver Enable from Shutdown to
Output High
tDZH(SHDN)
S2 closed, RL = 500I, CL = 100pF,
Figures 4 and 5
4500
ns
Driver Enable from Shutdown to
Output Low
tDZL(SHDN)
S1 closed, RL = 500I, CL = 100pF,
Figures 4 and 5
5200
ns
Driver Disable Delay
tDLZ, tDHZ Figures 4 and 5
100
ns
Driver Enable Delay
tDZL, tDZH Figures 4 and 5
2500
ns
RECEIVER
Receiver Propagation Delay
tRPLH
CL = 15pF, |VID| R 2.0V; tLH, tHL P 15ns,
Figures 6 and 7
200
ns
tRPHL
200
Receiver Output Skew
tRSKEW
CL = 15pF, Figures 6 and 7
30
ns
Maximum Data Rate
DRMAX
500
kbps
Receiver Enable to Output High
tRZH
S2 closed, CL = 100pF, RL = 500I,
Figures 8 and 9
50
ns
Receiver Enable to Output Low
tRZL
S1 closed, CL = 100pF, RL = 500I,
Figures 8 and 9
50
ns
Receiver Disable from High
tRHZ
Figures 8 and 9
50
ns
Receiver Disable from Low
tRLZ
Figures 8 and 9
50
ns
Receiver Enable from Shutdown
to Output High
tRZH(SHDN) Figures 8 and 9
5000
ns
Receiver Enable from Shutdown
to Output Low
tRZL(SHDN) Figures 8 and 9
5000
ns
TERMINATION RESISTOR
Turn-Off Time
tRTZ
Figure 10
120
F
s
Turn-On Time
tRTEN
Figure 10
1
F
s
