| 型號： | MAX4952CTO+ |
| 廠商： | Maxim Integrated Products |
| 文件頁數： | 9/11頁 |
| 文件大小： | 0K |
| 描述： | IC RE-DRIVER 4CH SAS/SATA 42TQFN |
| 產品培訓模塊： | Lead (SnPb) Finish for COTS Obsolescence Mitigation Program |
| 標準包裝： | 240 |
| 類型： | 轉接驅動器 |
| 驅動器/接收器數： | 4/0 |
| 規程： | SATA |
| 電源電壓： | 3.3V |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 42-WFQFN 裸露焊盤 |
| 供應商設備封裝： | 42-TQFN-EP（3.5x9） |
| 包裝： | 管件 |
MAX4952
Quad Equalized 1.5/3.0/6.0GT/s
SAS/SATA Redriver
_______________________________________________________________________________________
7
Pin Description
PIN
NAME
FUNCTION
1
MODEB
OOB Threshold Logic Input B. MODEB is internally pulled down.
2, 9, 16, 23,
30, 37
VCC
Positive Supply Voltage Input. Bypass VCC to GND with 2.2F and 0.01F capacitors in parallel as
close to the device as possible, recommended on each VCC pin.
3, 6, 12, 15,
24, 27, 33, 36
GND
Ground
4
IN1BP
Noninverting Input 1B
5
IN1BM
Inverting Input 1B
7
OUT0BP
Noninverting Output 0B
8
OUT0BM
Inverting Output 0B
10
IN0AP
Noninverting Input 0A
11
IN0AM
Inverting Input 0A
13
OUT1AP
Noninverting Output 1A
14
OUT1AM
Inverting Output 1A
17
ENA
Active-High Enable Input A. Drive ENA low to put A channels in standby mode. Drive ENA high to
put A channels in normal operation. ENA is internally pulled down.
18
EQ0A
Channel 0A Input Equalizer Logic Input. EQ0A is internally pulled down.
19
PE0A
Channel 0A Output Preemphasis Logic Input. PE0A is internally pulled down.
20
EQ1A
Channel 1A Input Equalizer Logic Input. EQ1A is internally pulled down.
21
PE1A
Channel 1A Output Preemphasis Logic Input. PE1A is internally pulled down.
22
MODEA
OOB Threshold Logic Input A. MODEA is internally pulled down.
25
IN1AM
Inverting Input 1A
26
IN1AP
Noninverting Input 1A
28
OUT0AM
Inverting Output 0A
29
OUT0AP
Noninverting Output 0A
31
IN0BM
Inverting Input 0B
32
IN0BP
Noninverting Input 0B
34
OUT1BM
Inverting Output 1B
35
OUT1BP
Noninverting Output 1B
38
ENB
Active-High Enable Input B. Drive ENB low to put B channels in standby mode. Drive ENB high to
put B channels in normal operation. ENB is internally pulled down.
39
EQ0B
Channel 0B Input Equalizer Logic Input. EQ0B is internally pulled down.
40
PE0B
Channel 0B Output Preemphasis Logic Input. PE0B is internally pulled down.
41
EQ1B
Channel 1B Input Equalizer Logic Input. EQ1B is internally pulled down.
42
PE1B
Channel 1B Output Preemphasis Logic Input. PE1B is internally pulled down.
—EP
Exposed Paddle. Internally connected to GND. EP must be electrically connected to a ground plane
for proper thermal and electrical operation. Do not use EP as the sole ground connection.
