M
10-Bit LVDS Serializer
6
_______________________________________________________________________________________
Typical Operating Characteristics
(V
CC
= +3.3V, R
L
= 50
Ω
, C
L
= 5pF, T
A
= +25°C, unless otherwise noted.)
28
31
32
33
30
29
34
3.0
3.3
3.1
3.2
SUPPLY VOLTAGE (V)
3.4
3.5
3.6
WORST-CASE PATTERN SUPPLY CURRENT
vs. SUPPLY VOLTAGE
M
S
TCLK = 40MHz
PIN
NAME
FUNCTION
1–7, 14, 15, 16
IN3–IN9, IN0,
IN1, IN2
LVCMOS/LVTTL Data Inputs. Data is loaded into a 10-bit latch by the rising TCLK edge. Each
input is internally pulled to ground.
8
TCLK
LVCMOS/LVTTL Reference Clock Input. Accepts a 16MHz to 40MHz clock. TCLK provides a
frequency reference to the PLL and strobes parallel data into the input latch on the rising edge.
9, 12
10
11
GND
OUT-
OUT+
Ground
Inverting Bus LVDS Differential Output
Noninverting Bus LVDS Differential Output
13
V
CC
Power-Supply Input. Bypass to ground with a 0.1μF capacitor and a 0.001μF capacitor. Place the
0.001μF capacitor closest to V
CC
.
Exposed Pad. Solder EP to ground for improved heat dissipation.
—
EP
