| 型號： | MAX9390EHJ+ |
| 廠商： | Maxim Integrated Products |
| 文件頁數： | 1/14頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC CROSSPOINT SWITCH DUAL 32TQFP |
| 產品培訓模塊： | Lead (SnPb) Finish for COTS Obsolescence Mitigation Program |
| 標準包裝： | 360 |
| 功能： | 交叉點開關 |
| 電路： | 2 x 2:2 |
| 電壓電源： | 單電源 |
| 電壓 - 電源，單路/雙路(±)： | 3 V ~ 3.6 V |
| 電流 - 電源： | 68mA |
| 工作溫度： | -40°C ~ 85°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 32-TQFP |
| 供應商設備封裝： | 32-TQFP（5x5） |
| 包裝： | 托盤 |
General Description
The MAX9390/MAX9391 dual 2 x 2 crosspoint switches
perform high-speed, low-power, and low-noise signal
distribution. The MAX9390/MAX9391 multiplex one of two
differential input pairs to either or both low-voltage differ-
ential signaling (LVDS) outputs for each channel.
Independent enable inputs turn on or turn off each differ-
ential output pair.
Four LVCMOS/LVTTL logic inputs (two per channel) con-
trol the internal connections between inputs and outputs.
This flexibility allows for the following configurations: 2 x 2
crosspoint switch, 2:1 mux, 1:2 splitter, or dual repeater.
This makes the MAX9390/MAX9391 ideal for protection
switching in fault-tolerant systems, loopback switching for
diagnostics, fanout buffering for clock/data distribution,
and signal regeneration.
Fail-safe circuitry forces the outputs to a differential low
condition for undriven inputs or when the common-
mode voltage exceeds the specified range. The
MAX9390 provides high-level input fail-safe detection
for LVDS, HSTL, and other GND-referenced differential
inputs. The MAX9391 provides low-level input fail-safe
detection for LVPECL, CML, and other VCC-referenced
differential inputs.
Ultra-low 82ps(P-P) (max) pseudorandom bit sequence
(PRBS) jitter ensures reliable communications in high-
speed links that are highly sensitive to timing error,
especially those incorporating clock-and-data recovery,
or serializers and deserializers. The high-speed switch-
ing performance guarantees 1.5GHz operation and less
than 65ps (max) skew between channels.
LVDS inputs and outputs are compatible with the
TIA/EIA-644 LVDS standard. The LVDS outputs drive
100
Ω loads. The MAX9390/MAX9391 are offered in a
32-pin TQFP package and operate over the extended
temperature range (-40°C to +85°C).
Also refer to the MAX9392/MAX9393 with flow-through
pinout.
Applications
High-Speed Telecom/Datacom Equipment
Central-Office Backplane Clock Distribution
DSLAM
Protection Switching
Fault-Tolerant Systems
Features
1.5GHz Operation with 250mV Differential Output
Swing
2ps(RMS) (max) Random Jitter
AC Specifications Guaranteed for 150mV
Differential Input
Signal Inputs Accept Any Differential Signaling
Standard
LVDS Outputs for Clock or High-Speed Data
High-Level Input Fail-Safe Detection (MAX9390)
Low-Level Input Fail-Safe Detection (MAX9391)
3.0V to 3.6V Supply Voltage Range
LVCMOS/LVTTL Logic Inputs Control Signal
Routing
MAX9390/MAX9391
Anything-to-LVDS Dual 2 x 2
Crosspoint Switches
________________________________________________________________ Maxim Integrated Products
1
TOP VIEW
MAX9390
MAX9391
TQFP
32
28
29
30
31
25
26
27
INA1
V
CC
ASEL0
ASEL1
INA0
GND
10
13
15
14
16
11
12
9
GND
INB0
BSEL0
V
CC
INB1
BSEL1
17
18
19
20
21
22
23 OUTA0
24 VCC
OUTA0
ENA0
GND
OUTA1
ENA1
2
3
4
5
6
7
8
VCC
OUTB0
GND
OUTB1
1
ENB1
ENB0
+
PART
TEMP RANGE
PIN-
PACKAGE
PKG
CODE
MAX9390EHJ
-40°C to +85°C
32 TQFP
H32-1
MAX9390EHJ+
-40°C to +85°C
32 TQFP
H32-1
MAX9391EHJ
-40°C to +85°C
32 TQFP
H32-1
MAX9391EHJ+
-40°C to +85°C
32 TQFP
H32-1
Pin Configurations
Ordering Information
19-2829; Rev 2; 5/07
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
+Denotes a lead-free package.
Functional Diagram and Typical Operating Circuit appear at
end of data sheet.
EVALUATION
KIT
AVAILABLE
