參數資料
型號： MAX9867EWV+T
廠商： Maxim Integrated Products
文件頁數： 14/55頁
文件大?。?/td> 0K
描述： IC STEREO AUD CODEC LP 30WLP
產品培訓模塊： Lead (SnPb) Finish for COTS
Obsolescence Mitigation Program
標準包裝： 1
類型： 立體聲音頻
數據接口： I²C，串行
分辨率（位）： 18 b
ADC / DAC 數量： 2 / 2
三角積分調變： 是
動態范圍，標準 ADC / DAC (db)： 85 / 90
電壓 - 電源，模擬： 1.65 V ~ 1.95 V
電壓 - 電源，數字： 1.65 V ~ 1.95 V
工作溫度： -40°C ~ 85°C
安裝類型： 表面貼裝
封裝/外殼： 30-WFBGA，WLBGA
供應商設備封裝： 30-WLP
包裝： 標準包裝
其它名稱： MAX9867EWV+TDKR
Detailed Description
The MAX9867 is a low-power stereo audio codec
designed for portable applications requiring minimum
power consumption.
The stereo playback path accepts digital audio through
a flexible interface compatible with I2S, TDM, and left-
justified signals. An oversampling sigma-delta DAC
converts the incoming digital data stream to analog
audio and outputs the audio through the stereo head-
phone amplifier. The headphone amplifier can be con-
figured in differential, single-ended, and capacitorless
output modes.
The stereo record path has two analog microphone
inputs with selectable gain. An integrated microphone
bias can be used to power the microphones. The left
analog microphone inputs can also accept data from
up to two digital microphones. An oversampling sigma-
delta ADC converts the microphone signals and out-
puts the digital bit stream over the digital audio
interface.
Integrated digital filtering provides a range of notch and
highpass filters for both the playback and record paths
to limit undesirable low-frequency signals and GSM
transmission noise. The digital filtering provides attenuation
of out-of-band energy by over 70dB, eliminating audi-
ble aliasing. A digital sidetone function allows audio
from the record path to be summed into the playback
path after digital filtering.
The MAX9867 also includes two stereo, single-ended
line inputs with gain adjustment, which can be record-
ed by the ADCs and/or output by the headphone ampli-
fiers. An auxiliary ADC accurately measures a DC
voltage by utilizing the right audio ADC and reporting
the DC voltage through the I2C interface. A jack detec-
tion function allows the detection of headphone, micro-
phone, and headset jacks. Insertion and removal
events can be programmed to trigger a hardware inter-
rupt and flag an I2C register bit.
The MAX9867’s flexible clock circuitry utilizes a program-
mable clock divider and a digital PLL, allowing the DAC
and ADC to operate at maximum dynamic range for all
combinations of master clock (MCLK) and sample rate
(LRCLK) without consuming extra supply current. Any
master clock between 10MHz and 60MHz is supported
as are all sample rates from 8kHz to 48kHz. Master and
slave modes are supported for maximum flexibility.
MAX9867
Ultra-Low Power Stereo Audio Codec
______________________________________________________________________________________
21
Pin Description (continued)
PIN/BUMP
TQFN-EP
WLP
NAME
FUNCTION
22
E3
LOUTP
Positive Left-Channel Headphone Output. Connect directly to the load in
differential and capacitorless mode. AC-couple to the load in single-ended mode.
23
E2
PVDD
Headphone Power Supply. Bypass to PGND with a 1F capacitor.
24, 25
—
N.C.
No Connection
26
E1
DVDDIO
Digital Audio Interface Power Supply. Bypass to DGND with a 1F capacitor.
27
D1
SDOUT
Digital Audio Serial-Data ADC Output
28
C2
SDIN
Digital Audio Serial-Data DAC Input
29
C1
LRCLK
Digital Audio Left-Right Clock Input/Output. LRCLK is the audio sample rate clock
and determines whether the audio data on SDIN is routed to the left or right
channel. In TDM mode, LRCLK is a frame synchronization pulse. LRCLK is an
input when the MAX9867 is in slave mode and an output when in master mode.
30
B1
BCLK
Digital Audio Bit Clock Input/Output. BCLK is an input when the MAX9867 is in
slave mode and an output when in master mode.
31
B2
MCLK
Master Clock Input. Acceptable input frequency range: 10MHz to 60MHz.
32
A1
DVDD
Digital Power Supply. Supply for the digital circuitry and I
2C interface. Bypass to
DGND with a 1F capacitor.
—
EP
Exposed Pad. Connect the exposed thermal pad to AGND.
