DS04-22113-3E
FUJITSU SEMICONDUCTOR
DATA SHEET
ASSP Communication Network
CMOS
LAN Controller with PC Card, ISA Bus, and
General-purpose Bus Interfaces
MB86967
I
DESCRIPTION
The MB86967 is a highly-integrated, high-performance single-chip Ethernet LAN controller which contains a
PC card interface based on the JEIDA4.2 standard, an ISA bus interface that can be connected directly to the
ISA bus, a general-purpose bus interface, a Manchester encoder/decoder based on the IEEE802.3 standard,
and 10BASE-T transceiver.
The LAN controller and buffer manager are software compatible with the MB86965A and MB86964. The buffer
manager has functions for arbitration and buffer management of external buffer memory (SRAM) which can be
expanded to 32 KB. These functions provide simultaneous access from the host and data link controller and
updating of transmit and receive buffer pointers. This permits substantial reduction of software overhead in buffer
management.
The Manchester encoder/decoder and 10BASE-T transceiver can be easily interfaced with twisted-pair cable
just by addition of a pulse transformer and filter.
Mode pin setting allows the system interface to switch between the PC card interface, ISA bus interface, and
general-purpose bus interface. When in the ISA bus interface mode, two modes can be selected: a jumperless
mode allowing software setting of I/O addresses and interrupt signals, and a jumper mode allowing DIPswitch
setting.
I
FEATURES
System Interface
Allows switching between PC card interface, ISA bus interface, and general-purpose bus interface
Allows byte swapping of word data according to host CPU (in ISA bus mode and general-purpose bus mode)
(Continued)
I
PACKAGE
100-pin Plastic LQFP
(FPT-100P-M05)
