MB89130/130A Series
I
PROGRAMMING TO THE EPROM ON THE MB89P135A
The MB89P135A is an OTPROM version of the MB89133A/135A.
1. Features
16-Kbyte PROM on chip
Equivalency to the MBM27C256A in EPROM mode (when programmed with the EPROM programmer)
2. Memory Space
Memory space in EPROM mode is diagrammed below.
3. Programming to the EPROM
In EPROM mode, the MB89P135A functions equivalent to the MBM27C256A. This allows the PROM to be
programmed with a general-purpose EPROM programmer (the electronic signature mode cannot be used) by
using the dedicated socket adapter.
Programming procedure
(1) Set the EPROM programmer for the MBM27C256A.
(2) Load program data into the EPROM programmer at 4000
H
to 7FFF
H
(note that addresses C000
H
to FFFF
H
while operating as a single chip correspond to 4000
H
to 7FFF
H
in EPROM mode).
(3) Load option data into the EPROM programmer at 3FF0
H
to 3FF6
H
.
(4) Program with the EPROM programmer.
0000
H
0080
H
BFF6
H
BFF0
H
C000
H
FFFF
H
I/O
RAM
Not available
Not available
Not available
Not available
PROM
16 KB
EPROM mode
(Corresponding addresses on the EPROM programmer)
Single chip
Address
0280
H
8000
H
Vacancy
(Read value FF
H
)
Vacancy
(Read value FF
H
)
Option area
EPROM
16 KB
0000
H
3FF6
H
7FFF
H
3FF0
H
4000
H
