MB91660 Series
112
DS07-16905-3E
(15) I2C Timing
Not using USB : (VCC
= AVCC = 2.7 V to 3.6 V, VSS = AVSS = 0 V, Ta = 40 °C to + 85 °C)
Using USB : (VCC
= AVCC = 3.0 V to 3.6 V, VSS = AVSS = 0 V, Ta = 40 °C to + 85 °C)
*1 : R and C represent the pull-up resistance and load capacitance of the SCL and SDA lines, respectively. Vp
indicates the power supply voltage of the pull-up resistance and IOL indicates VOL guaranteed current.
*2 : The maximum tHDDAT must satisfy that it doesn't extend at least “L” period (tLOW) of device's SCL signal.
*3 : A high-speed mode I2C bus device can be used on a standard mode I2C bus system as long as the device
satisfies the requirement of “tSUDAT
≥ 250 ns”.
*4 : tCYCP is the peripheral clock cycle time. To use I2C, set the peripheral bus clock at 8 MHz or more.
Parameter
Symbol
Pin name
Condi-
tions
Typical mode
High-speed mode*3
Unit
Min
Max
Min
Max
SCL clock frequency
fSCL
SCKn
(SCLn)
CL
= 50 pF,
R
=
(Vp/IOL) *1
01000400
kHz
“(Repeated) START
condition” hold time
SDA
↓ → SCL ↓
tHDSTA
SOUTn
(SDAn)
SCKn
(SCLn)
4.0
0.6
s
SCL clock “L” width
tLOW
SCKn
(SCLn)
4.7
1.3
s
SCL clock “H” width
tHIGH
SCKn
(SCLn)
4.0
0.6
s
“Repeated START
condition” setup time
SCL
↑→ SDA ↓
tSUSTA
SCKn
(SCLn)
4.7
0.6
s
Data hold time
SCL
↓ → SDA ↓ ↑
tHDDAT
SOUTn
(SDAn)
SCKn
(SCLn)
0
3.45*2
00.9*3
s
Data setup time
SDA
↓ ↑→ SCL↑
tSUDAT
SOUTn
(SDAn)
SCKn
(SCLn)
250
100
ns
“STOP condition” setup
time
SCL
↑→ SDA↑
tSUSTO
SOUTn
(SDAn)
SCKn
(SCLn)
4.0
0.6
s
Bus free time between
“STOP condition” and
“START condition”
tBUF
4.7
1.3
s
Noise filter
tSP
2 tCYCP *4
2 tCYCP *4
ns
