MB96380 Series
80
FME-MB96380 rev 10
Power supply cur-
rent in Stop Mode
ICCH
VRCR:LPMB[2:0] = 110B
(Core voltage at 1.8V)
+25C
0.02
0.08
mA
MB96384/385
+125C
0.4
1.5
+25C
0.02
0.08
mA
MB96F385
+125C
0.4
1.5
+25C
0.02
0.08
mA
MB96F386/F387
+125C
0.52
2.8
+25C
0.02
0.08
mA
MB96F388/F389
+125C
0.52
2.2
VRCR:LPMB[2:0] = 000B
(Core voltage at 1.2V)
+25C
0.015
0.06
mA
MB96384/385
+125C
0.3
1.2
+25C
0.015
0.06
mA
MB96F385
+125C
0.3
1.2
+25C
0.015
0.06
mA
MB96F386/F387
+125C
0.4
2.3
+25C
0.015
0.06
mA
MB96F388/F389
+125C
0.4
1.65
Power supply cur-
rent for active Low
Voltage detector
ICCLVD
Low voltage detector en-
abled (RCR:LVDE = 1)
+25C
90
140
A
This current must be
added to all Power
supply currents above
+125C
100
150
Power supply cur-
rent for active
Clock modulator
ICCCLOMO
Clock modulator enabled
(CMCR:PDX = 1)
-
3
4.5
mA
Must be added to all
current above
Flash Write/Erase
current
ICCFLASH
Current for one Flash
module
-15
40
mA
Must be added to all
current above
Input capacitance
CIN
-
15
30
pF
High current outputs
Input capacitance
CIN
--
5
15
pF
Other than C, AVCC,
AVSS, AVRH, AVRL,
VCC, VSS, DVCC, DVSS,
High current outputs
* The power supply current is measured with a 4MHz external clock connected to the Main oscillator and a 32kHz
external clock connected to the Sub oscillator. See chapter “Standby mode and voltage regulator control circuit” of
the Hardware Manual for further details about voltage regulator control.
(TA = -40C to 125C, VCC = AVCC = 3.0V to 5.5V, DVCC = 3.0V to 5.5V, VSS = AVSS = DVSS = 0V)
Parameter
Symbol
Condition (at TA)
Value
Remarks
Typ
Max
Unit
