參數資料
型號： MBRB2060CT
廠商： ON SEMICONDUCTOR
元件分類： 參考電壓二極管
英文描述： Schottky Barrier Power Rectifier(20A,60V肖特基勢壘功率整流器（表貼封裝）)
中文描述： 10 A, 60 V, SILICON, RECTIFIER DIODE
封裝： PLASTIC, CASE 418B-04, D2PAK-3
文件頁數： 1/4頁
文件大?。?/td> 54K
代理商： MBRB2060CT
Semiconductor Components Industries, LLC, 2005
September, 2005 Rev. 6
1
Publication Order Number:
MBRB2060CT/D
MBRB2060CT
Preferred Device
SWITCHMODE
Power Rectifier
D
2
PAK Surface Mount Power Package
These stateoftheart devices employ the use of the Schottky
Barrier principle with a platinum barrier metal.
Features
Package Designed for Power Surface Mount Applications
CenterTap Configuration
Guardring for Stress Protection
Low Forward Voltage
150
°
C Operating Junction Temperature
Epoxy Meets UL 94 V0 @ 0.125 in
Short Heat Sink Tab Manufactured Not Sheared
Similar in Size to Industry Standard TO220 Package
PbFree Packages are Available
Mechanical Characteristics:
Case: Epoxy, Molded, Epoxy Meets UL 94 V0
Weight: 1.7 Grams (Approximately)
Finish: All External Surfaces Corrosion Resistant and Terminal
Leads are Readily Solderable
Lead and Mounting Surface Temperature for Soldering Purposes:
260
°
C Max. for 10 Seconds
Device Meets MSL1 Requirements
ESD Ratings: Machine Model, C (>400 V)
Human Body Model, 3B (>8000 V)
MAXIMUM RATINGS
(Per Leg)
Rating
Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
I
F(AV)
60
V
Average Rectified Forward Current
(Rated V
R
, T
C
= 110
°
C) Total Device
10
20
A
Peak Repetitive Forward Current
(Rated V
R
, Square Wave,
20 kHz, T
C
= 100
°
C)
NonRepetitive Peak Surge Current
(Surge Applied at Rated Load Conditions
Halfwave, Single Phase, 60 Hz)
I
FRM
20
A
I
FSM
150
A
Peak Repetitive Reverse Surge Current
(2.0 s, 1.0 kHz)
I
RRM
0.5
A
Storage Temperature Range
T
stg
T
J
dv/dt
65 to +175
°
C
°
C
Operating Junction Temperature
65 to +150
Voltage Rate of Change (Rated V
R
)
Maximum ratings are those values beyond which device damage can occur.
Maximum ratings applied to the device are individual stress limit values (not
normal operating conditions) and are not valid simultaneously. If these limits are
exceeded, device functional operation is not implied, damage may occur and
reliability may be affected.
10,000
V/ s
SCHOTTKY BARRIER
RECTIFIER
20 AMPERES, 60 VOLTS
1
3
4
Preferred
devices are recommended choices for future use
and best overall value.
http://onsemi.com
See detailed ordering and shipping information in the package
dimensions section on page 2 of this data sheet.
ORDERING INFORMATION
D
2
PAK
CASE 418B
STYLE 3
3
4
1
MARKING DIAGRAM
B2060G
AKA
A
Y
WW
B2060
G
AKA
= Assembly Location
= Year
= Work Week
= Device Code
= PbFree Package
= Diode Polarity
AY WW
