ML2035
4
REV. 1.0 10/10/2000
ELECTRICAL CHARACTERISTICS
(Continued)
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNITS
LOGIC
(Continued)
V
OL
Output Low Voltage
I
OL
= -2mA
0.4
V
V
OH
Output High Voltage
I
OH
= 2mA
4.0
V
t
SCK
Serial Clock On/Off Period
100
ns
t
DS
SID Data Setup Time
50
ns
t
DH
SID Data Hold Time
50
ns
t
LPW
LATI Pulse Width
50
ns
t
LH
LATI Hold Time
50
ns
t
LS
LATI Setup Time
50
ns
SUPPLY
I
CC
V
CC
Current
No Load, V
CC
= 5.5V
5.5
mA
No Load, Power Down Mode
2
mA
I
SS
V
SS
Current
No Load, V
CC
= 5.5V, V
SS
= -5.5V
-3.5
mA
No Load, Power Down Mode
-100
μ
A
Note 1:
Limits are guaranteed by 100% testing, sampling, or correlation with worst case test conditions.
Figure 1. Serial Interface Timing.
Figure 2. CLK IN Input Current vs. Input Voltage.
100
75
50
25
0
-25
-50
-75
-100
I
INPUT VOLTAGE (V)
0
1
3
5
4
2
CLK IN
SCK
SID
LATI
t
LPW
t
LS
t
LH
t
DS
t
DH
t
SCK
t
SCK
t
CKI
t
CKI
