參數資料
型號： MM74C14N_NL
廠商： FAIRCHILD SEMICONDUCTOR CORP
元件分類： 門電路
英文描述： Hex Schmitt Trigger
中文描述： CMOS SERIES, HEX 1-INPUT INVERT GATE, PDIP14
封裝： 0.300 INCH, LEAD FREE, PLASTIC, MS-001, DIP-14
文件頁數： 2/6頁
文件大小： 66K
代理商： MM74C14N_NL
www.fairchildsemi.com
2
MM
74C14
Absolute Maximum Ratings(Note 1)
Note 1: “Absolute Maximum Ratings” are those values beyond which the
safety of the device cannot be guaranteed. Except for “Operating Tempera-
ture Range” they are not meant to imply that the devices should be oper-
ated at these limits. The Electrical Characteristics tables provide conditions
for actual device operation.
DC Electrical Characteristics
Min/Max limits apply across the guaranteed temperature range unless otherwise noted
Note 2: Only one of the six inputs is at VCC; the others are either at VCC or GND.
Voltage at Any Pin
0.3Vto V
CC + 0.3V
Operating Temperature Range
55°C to +125°C
Storage Temperature Range
65°C to +150°C
Power Dissipation
Dual-In-Line
700 mW
Small Outline
500mW
Operating VCC Range
3.0V to 15V
Absolute Maximum VCC
18V
Lead Temperature
(Soldering, 10 seconds)
260
°C
Symbol
Parameter
Conditions
Min
Typ
Max
Units
CMOS TO CMOS
VT+
Positive Going Threshold Voltage
VCC = 5V
3.0
3.6
4.3
V
VCC = 10V
6.0
6.8
8.6
VCC = 15V
9.0
10.0
12.9
VT
Negative Going Threshold Voltage
VCC = 5V
0.7
1.4
2.0
V
VCC = 10V
1.4
3.2
4.0
VCC = 15V
2.1
5.0
6.0
VT+ – VT
Hysteresis
VCC = 5V
1.0
2.2
3.6
V
VCC = 10V
2.0
3.6
7.2
VCC = 15V
3.0
5.0
10.8
VOUT(1)
Logical “1” Output Voltage
VCC = 5V, IO = 10 A4.5
V
VCC = 10V, IO = 10 A9.0
VOUT(0)
Logical “0” Output Voltage
VCC = 5V, IO = 10 A0.5
V
VCC = 10V, IO = 10 A1.0
IIN(1)
Logical “1” Input Current
VCC = 15V, VIN = 15V
0.005
1.0
A
IIN(0)
Logical “0” Input Current
VCC = 15V, VIN = 0V
1.0
0.005
A
ICC
Supply Current
VCC = 15V, VIN = 0V/15V
0.05
15
A
VCC = 5V, VIN = 2.5V (Note 2)
20
VCC = 10V, VIN = 5V (Note 2)
200
VCC = 15V, VIN = 7.5V (Note 2)
600
CMOS/LPTTL INTERFACE
VIN(1)
Logical “1” Input Voltage
VCC = 5V
4.3
V
VIN(0)
Logical “0” Input Voltage
VCC = 5V
0.7
V
VOUT(1)
Logical “1” Output Voltage
74C, VCC = 4.75V, IO = 360 A2.4
V
VOUT(0)
Logical “0” Output Voltage
74C, VCC = 4.75V, IO = 360 A0.4
V
OUTPUT DRIVE (see Family Characteristics Data Sheet) TA = 25°C (Short Circuit Current)
ISOURCE
Output Source Current
VCC = 5V, VOUT = 0V
1.75
3.3
mA
(P-Channel)
ISOURCE
Output Source Current
VCC = 10V, VOUT = 0V
8.0
15
mA
(P-Channel)
ISINK
Output Sink Current
VCC = 5V, VOUT = VCC
1.75
3.6
mA
(N-Channel)
ISINK
Output Sink Current
VCC = 10V, VOUT = VCC
8.0
16
mA
(N-Channel)
