MR2502, MR2504, MR2510
http://onsemi.com
8
PACKAGE DIMENSIONS
MICRODE BUTTON
CASE 193–04
ISSUE J
A
D
B
F
M
DIM
A
B
D
F
M
MIN
8.43
4.19
5.54
5.94
MAX
8.69
4.45
5.64
6.25
MIN
0.332
0.165
0.218
0.234
MAX
0.342
0.175
0.222
0.246
INCHES
MILLIMETERS
5 NOM
5 NOM
