Semiconductor
MSM6882-3/6882-5
This version: Jan. 1998
Previous version: Nov. 1996
1/15
2400/1200 bps Single Chip MSK Modem
GENERAL DESCRIPTION
The MSM6882-3/6882-5 is a single chip MSK (Minimum Shift Keying) modem which is fabricated
by Oki’s low power consumption CMOS silicon gate technology.
The demodulator receives the data to be transmitted (SD) synchronized with the transmit timing
clock (ST) generated by the on-chip clock generator. The signal, which is modulated by MSK method,
is output.
The demodulator converts the received MSK signal to the received data (RD) by means of a delay
detection technique after limiting the band of the received MSK signal. This signal is input to the
digital PLL and the re-generated timing clock (RT) is output from the demodulator, synchronized
FEATURES
Signal power supply:+3.6 V
(MSM6882-3)
(MSM6882-5)
+5 V
On-chip SCF (Switched Capacitor Filter)
The transmit filter can be also used as voice splatter filter.
The receive timing re-generator has two different lock-in time performance options to be chosen
from.
Bit rate 2400/1200 bps
CCIR Rec. 623
The modulation method can be selected from COS-FFSK and SIN-FFSK.
Built-in crystal oscillation circuit.
Package options:
22-pin plastic DIP
(DIP22-P-400-2.54)
(Product name: MSM6882-3RS)
(Product name: MSM6882-5RS)
(Product name: MSM6882-3GS-K)
(Product name: MSM6882-5GS-K)
24-pin plastic SOP
(SOP24-P-430-1.27-K)
E2A0035-16-X0
