+5V Multiprotocol, 3Tx/3Rx, Software-
Selectable Clock/Data Transceivers
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
All Voltages Referenced to GND Unless Otherwise Noted.
Supply Voltages
V
CC
.......................................................................-0.3V to +6V
V
DD
....................................................................-0.3V to +7.3V
V
EE
.....................................................................+0.3V to -6.5V
V
DD
to V
EE
(Note 1)................................................................13V
Logic Input Voltages
M0, M1, M2, DCE/
DTE
, T_IN................................-0.3V to +6V
Logic Output Voltages
R_OUT....................................................-0.3V to (V
CC
+ 0.3V)
Transmitter Outputs
T_OUT_, T3OUT_/R1IN_.....................................-15V to +15V
Short-Circuit Duration............................................Continuous
Note 1:
V
DD
and V
EE
absolute difference cannot exceed 13V.
ELECTRICAL CHARACTERISTICS
(V
CC
= +5.0V, C1 = C2 = C4 = 1μF, C3 = C5 = 4.7μF, (Figure 10), T
A
= T
MIN
to T
MAX
. Typical values are at T
A
= +25°C, unless oth-
erwise noted.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Receiver Input
R_IN_T3OUT_/R1IN_..........................................-15V to +15V
Continuous Power Dissipation (T
A
= +70°C)
28-Pin SSOP (derate 11.1mW/°C above +70°C) .........889mW
Operating Temperature Range
MXL1543CAI .......................................................0°C to 70°C
Junction Temperature .......................................................150°C
Storage Temperature Range ...........................-65°C to +150°C
Lead Temperature (soldering, 10s) ...............................+300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
DC CHARACTERISTICS
V
CC
Operating Range
V
CC
4.75
5.25
V
RS-530, RS-530A, X.21, no load
RS-530, RS-530A, X.21, full load
V.35 mode, no load
V.35 mode, full load
V.28 mode, no load
V.28 mode, full load
No-cable mode
RS-530, RS-530A, X.21, full load
V.35 mode, full load
V.28 mode, full load
Any mode (except no-cable mode), no load
V.28 mode, with load
V.28, V.35 modes, with load, I
DD
= 10mA
V.28, V.35, no load
V.28 mode, full load
V.35 mode, full load
RS-530, RS-530A, X.21, full load
No-cable mode or power-up to turn on
13
100
20
126
20
40
0.5
230
600
140
6.8
6.8
6.8
-5.6
-5.6
-5.6
-5.6
500
130
170
75
10
mA
Supply Current
(DCE Mode)
(Digital Inputs = GND or
V
CC
)
(Transmitter Outputs Static)
I
CC
μ
A
Internal Power Dissipation
(DCE Mode)
P
D
mW
6.4
6.4
6.4
Positive Charge-Pump
Output Voltage
V
DD
V
-5.4
-5.4
-5.4
Negative Charge-Pump
Output Voltage
V
EE
V
Supply Rise Time
LOGIC INPUTS (M0, M1, M2, DCE/
DTE
, T1IN, T2IN, T3IN)
Input High Voltage
Input Low Voltage
t
r
μs
V
IH
V
IL
2.0
0.8
±10
-30
±
10
V
T1IN, T2IN, T3IN
M0, M1, M2, DCE/
DTE
= GND
M0, M1, M2, DCE/
DTE
= V
CC
-100
-50
Logic Input Current
I
IN
μ
A
