Philips Semiconductors
Product specification
PowerMOS transistors
Avalanche energy rated
PHP3N40E, PHB3N40E, PHD3N40E
FEATURES
SYMBOL
QUICK REFERENCE DATA
Repetitive Avalanche Rated
Fast switching
Stable off-state characteristics
High thermal cycling performance
Low thermal resistance
V
DSS
= 400 V
I
D
= 2.5 A
R
DS(ON)
≤
3.5
GENERAL DESCRIPTION
N-channel,enhancement modefield-effectpower transistor,intendedforusein off-lineswitchedmode powersupplies,
T.V.and computer monitor powersupplies, d.c. tod.c.converters, motor controlcircuits and generalpurpose switching
applications.
The PHP3N40E is supplied in the SOT78 (TO220AB) conventional leaded package.
The PHB3N40E is supplied in the SOT404 surface mounting package.
The PHD3N40E is supplied in the SOT428 surface mounting package.
PINNING
SOT78 (TO220AB)
SOT404
SOT428
PIN
DESCRIPTION
1
gate
2
drain
1
3
source
tab
drain
LIMITING VALUES
Limiting values in accordance with the Absolute Maximum System (IEC 134)
SYMBOL PARAMETER
V
DSS
Drain-source voltage
V
DGR
Drain-gate voltage
V
GS
Gate-source voltage
I
D
Continuous drain current
CONDITIONS
T
j
= 25 C to 150C
T
j
= 25 C to 150C; R
GS
= 20 k
MIN.
-
-
-
-
-
-
-
- 55
MAX.
400
400
±
30
2.5
1.5
10
50
150
UNIT
V
V
V
A
A
A
W
C
T
mb
= 25 C; V
GS
= 10 V
T
mb
= 100 C; V
GS
= 10 V
T
mb
= 25 C
T
mb
= 25 C
I
DM
P
D
T
j
, T
stg
Pulsed drain current
Total dissipation
Operating junction and
storage temperature range
d
g
s
1 2 3
tab
1
3
tab
2
1
2
3
tab
1
It is not possible to make connection to pin 2 of the SOT428 or SOT404 packages.
August 1998
1
Rev 1.100
