Sensors
SA1A and SA1B: High-Speed, Slim Style Photoelectric Sensors
www.idec.com
USA: (800) 262-IDEC or (408) 747-0550, Canada: (888) 317-IDEC
Q-47
Q
S
Key features of the SA1A and SA1B include:
Ideal for installations with broad or narrow clearances
Available with through-beam between the projector and receiver, which
features a sensing range of 6'–6-3/4" (2m)
Sensing by diffuse-reflected light available, with a sensitivity adjustment for eliminating the interference of
background light
Through-beam and diffuse-reflected light sensors are featured in
all configurations
Configurations include NPN or PNP transistor output, with light on or dark
on (senses the presence or absence of an object)
Adverse results and circuit damage are avoided through protection from
reverse polarity
High-speed, 1ms response time
Automatic reset with power-up
Protection rated IP66
G
Power Voltage
Operating Voltage
Current Draw
Dielectric Strength
Insulation Resistance
Operating Humidity
Operating Tempera-
ture
Storage Temperature
Vibration Resistance
Shock Resistance
12V to 24V DC
10V to 30V DC, (ripple 10% maximum)
25mA (maximum)
Between live and dead parts: 1,000V AC, 50/60Hz, 1 minute
Between live and dead parts: 20M
(minimum), with 500V DC megger
35 to 85% RH (avoid condensation)
–15° to +55°C (avoid freezing)
–25° to +65°C
Damage limits: 10 to 55Hz, amplitude 1.5mm p-p, 2 hours in each of 3 axes
Damage limits: 500m/s
2
(approximately 50G), 10 shocks in each of 3 axes
Sunlight: 10,000 lux (maximum), Incandescent light: 3,000 lux (maximum) —
defined as incident or unwanted light received by a sensor, unrelated to the presence or
absence of the intended object
Housing and lens: polycarbonate
IP66 — IEC Pub 529, sensors rated IP66 are dust-tight, water-resistant, and perform best
when not subjected to heavy particle or water blasts
Cable type: 0.2mm
2
; Vinyl cabtyre cable #26 AWG x 6'–6-3/4" (2m) long
Transmitter: 2-core, Receiver: 4-core
328' (100m) maximum using #22 AWG (0.3mm
2
) cabtyre cable or better
Projector: 40g; Receiver: 45g
Extraneous Light
Immunity
Material
Degree of Protection
Cable
Cable Extension
Weight
Narrow/Flat Type
SA1A/B-TN1, -TN2
SA1A/B-DN1, -DN2
SA1A/B-TP1, -TP2
SA1A/B-DP1, -DP2
F
Detection
Through-beam
Diffuse-reflected
light
Through-beam
Diffuse-reflected
light
Sensitivity
Hysteresis
––––
Adjustable
––––
Adjustable
––––
20% (maximum)
––––
20% (maximum)
Output
NPN transistor open collector
30V DC, 100mA (maximum)
PNP transistor open collector
30V DC, 100mA (maximum)
Light Source
LED
Response
Infrared LED (modulation mode)
On: When output is on
1ms (maximum)
SA1A and SA1B: High-Speed, Slim Style Photoelectric Sensors
