參數資料
| 型號： | PSK5A18-2B |
| 廠商： | POWER-ONE INC |
| 元件分類： | 電源模塊 |
| 英文描述： | 1-OUTPUT DC-DC REG PWR SUPPLY MODULE |
| 封裝： | METAL, CASE K01, MODULE |
| 文件頁數： | 10/15頁 |
| 文件大?。?/td> | 311K |
| 代理商： | PSK5A18-2B |
PSS, PSK Extended Data Sheet
Positive Switching Regulators (Benign)
REV. FEB 15, 2004
Page 4 of 15
Electrical Output Data
General Conditions:
–
TA = 25°C, unless TC is specified
– With R control output voltage
Vo = Vo nom at Io nom
– Sense lines connected at female connector
Table 3a: Output data PSS
Output
PSS 5A14
PSS 1214
PSS 1214 1
PSS 2414
Characteristics
Conditions
min typ max
Unit
Vo
Output voltage
Vi nom, Io nom
5.05
5.15
11.60
12.40 14.50
15.50 23.30
24.70
V
Io
Output current 2
Vi min – Vi max
0
14.0
0
14.0
0
14.0
0
14.0
A
IoL
Output current limitation
TC min – TC max
14.0
17.5
14.0
17.5
14.0
17.5
14.0
17.5
response
vo
Output
Switching freq.
Vi nom, Io nom
55
150
200
300
mVpp
voltage
Total
IEC/EN 61204 3
60
160
210
310
noise
BW = 20 MHz
DVo U
Static line regulation
Vi min –Vi max, Io nom
100
240
300
480
mV
DVo l
Static load regulation
Vi nom, Io = 0 – Io nom
100
120
150
240
vo d
Dynamic
Voltage deviat.
Vi nom
150
360
450
700
td
load
Recovery time
Io nom
1/3Ionom
40
60
s
regulation
IEC/EN 61204
aUo
Temperature coefficient
Vi min – Vi max
±1
±2
±3
±5
mV/K
DVo/DTC (TC min – TC max)
Io = 0 – Io nom
±0.02
%/K
Table 3b: Output data PSK
Output
PSK 5A18
PSK 1218
PSK 1218 1
PSK 2418
Characteristics
Conditions
min typ max
Unit
Vo
Output voltage
Vi nom, Io nom
5.05
5.15
11.60
12.40 14.50
15.50 23.30
24.70
V
Io
Output current 2
Vi min – Vi max
0
18.0
0
18.0
0
18.0
0
18.0
A
IoL
Output current limitation
TC min – TC max
18.0
22.5
18.0
22.5
18.0
22.5
18.0
22.5
response
vo
Output
Switching freq.
Vi nom, Io nom
55
150
200
300
mVpp
voltage
Total
IEC/EN 61204 3
60
160
210
310
noise
BW = 20 MHz
DVo U
Static line regulation
Vi min – Vi max, Io nom
100
240
300
480
mV
DVo l
Static load regulation
Vi nom, Io = 0 – Io nom
100
120
150
240
vo d
Dynamic
Voltage deviat.
Vi nom
150
360
450
700
td
load
Recovery time
Io nom
1/3Ionom
40
60
s
regulation
IEC/EN 61204
aUo
Temperature coefficient
Vi min – Vi max
±1
±2
±3
±5
mV/K
DVo/DTC (TC min – TC max)
Io = 0 – Io nom
±0.02
%/K
1 Output set to 15 V at R control input, see: Auxiliary Functions.
2 See also: Thermal Considerations.
