參數資料
型號： PT7C4307WEX
廠商： Pericom
文件頁數： 13/16頁
文件大?。?/td> 0K
描述： IC RTC ALARM NVSRAM 8SOIC
標準包裝： 1
類型： 時鐘/日歷
特點： 警報器，閏年，NVSRAM，方波輸出
存儲容量： 56B
時間格式： HH:MM:SS（12/24 小時）
數據格式： YY-MM-DD-dd
接口： I²C，2 線串口
電源電壓： 4.5 V ~ 5.5 V
電壓 - 電源，電池： 2 V ~ 3.5 V
工作溫度： -40°C ~ 85°C
安裝類型： 表面貼裝
封裝/外殼： 8-SOIC（0.154"，3.90mm 寬）
供應商設備封裝： 8-SOIC
包裝： 標準包裝
其它名稱： PT7C4307WEXDKR
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PT0206(08/09)
Ver: 3
6
Data Sheet
PT7C4307
Real-time Clock Module (I
2C Bus)
12, /24 bit
This bit is used to select between 12-hour clock system and 24-hour clock system.
12, /24
Data
Description
0
24-hour system
Read / Write
1
12-hour system
This bit is used to select between 12-hour clock operation and 24-hour clock operation.
12, /24
Description
Hours register
0
24-hour time display
1
12-hour time display
* Be sure to select between 12-hour and 24-hour clock operation before writing the time data.
Days of the week Counter
The day counter is a divide-by-7 counter that counts from 01 to 07 and up 07 before starting again from 01. Values that
correspond to the day of week are user defined but must be sequential (i.e., if 1 equals Sunday, then 2 equals Monday, and so on).
Illogical time and date entries result in undefined operation.
Addr.
(hex)
Description
D7
D6
D5
D4
D3
D2
D1
D0
Days of the week
0
W4
W2
W1
03
(default)
0
Undefined Undefined Undefined
Calendar Counter
The data format is BCD format.
Day digits: Range from 1 to 31 (for January, March, May, July, August, October and December).
Range from 1 to 30 (for April, June, September and November).
Range from 1 to 29 (for February in leap years).
Range from 1 to 28 (for February in ordinary years).
Carried to month digits when cycled to 1.
Month digits: Range from 1 to 12 and carried to year digits when cycled to 1.
Year digits: Range from 00 to 99 and 00, 04, 08, … , 92 and 96 are counted as leap years.
24-hour clock
12-hour clock
24-hour clock
12-hour clock
00
52 ( AM 12 )
12
72 ( PM 12)
01
41 ( AM 01 )
13
61 ( PM 01 )
02
42 ( AM 02 )
14
62 ( PM 02 )
03
43 ( AM 03 )
15
63 ( PM 03 )
04
44 ( AM 04 )
16
64 ( PM 04 )
05
45 ( AM 05 )
17
65 ( PM 05 )
06
46 ( AM 06 )
18
66 ( PM 06 )
07
47 ( AM 07 )
19
67 ( PM 07 )
08
48 ( AM 08 )
20
68 ( PM 08 )
09
49 ( AM 09 )
21
69 ( PM 09 )
10
50 ( AM 10 )
22
70 ( PM 10 )
11
51 ( AM 11 )
23
71 ( PM 11 )
相關PDF資料
PDF描述
PT7C4311WEX IC RTC LEAP YEAR Y2K 8SOIC
PT7C43390WEX IC REAL TIME CLOCK 8SOIC
PT7C4563UEX IC REAL TIME CLOCK 8MSOP
QPI-12LZ-01 IC INTERFACE FILTER
QPI-5LZ FILTER 24V 14A ACTIVE EMI
相關代理商/技術參數
參數描述
PT7C4311WEX 功能描述:IC RTC LEAP YEAR Y2K 8SOIC RoHS:是 類別:集成電路 (IC) >> 時鐘/計時 - 實時時鐘 系列:- 標準包裝:2,500 系列:- 類型:時鐘/日歷 特點:警報器，閏年，監控器，監視計時器 存儲容量:- 時間格式:HH:MM:SS（12/24 小時） 數據格式:YY-MM-DD-dd 接口:I²C，2 線串口 電源電壓:2.7 V ~ 5.5 V 電壓 - 電源，電池:1.8 V ~ 5.5 V 工作溫度:-40°C ~ 85°C 安裝類型:表面貼裝 封裝/外殼:14-TSSOP（0.173"，4.40mm 寬） 供應商設備封裝:14-TSSOP 包裝:帶卷 (TR)
PT7C4337 制造商:未知廠家 制造商全稱:未知廠家 功能描述:Real-time Clock Module (I2C Bus)
PT7C4337PE 制造商:未知廠家 制造商全稱:未知廠家 功能描述:Real-time Clock Module (I2C Bus)
PT7C4337UE 制造商:Pericom Semiconductor Corporation 功能描述:
PT7C4337WE 制造商:Pericom Semiconductor Corporation 功能描述:1.8V - 5.5V, REA TIME CLOCK, 12C BUS, ALARM/CLOCK OUTPUT - Bulk
