RE028 4.5V 30mA LDO Voltage Regulator
2704B–PMGMT–03/03
Absolute Maximum Ratings
*
V
IN
..........................................................-0.3V to 6.5V
Electrical Specifications
(1)
T
J
= -20
°
C to 125
°
C, V
IN7
= 4.75V to 5.5V unless otherwise specified, output capacitance = 2.2 μF.
*NOTICE:
Stresses beyond those listed under “Absolute Maxi-
mum Ratings” may cause permanent damage to the
device. This is a stress rating only and functional
operation of the device at these or other conditions
beyond those indicated in the operational sections of
this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may
affect device reliability.
Digital Signals.........................................-0.3V to 5.5V
Output Current..................................Internally Limited
Junction Temperature..........................-40
°
C to 150
°
C
Table 1.
Electrical Specifications
Symbol
Parameter
Condition
Min
Typ
Max
Unit
V
IN7
Operating supply voltage
4.75
5.1
5.5
V
V
SAUVC
Auxiliary operating supply voltage
2.4
2.5
2.6
V
T
J
Junction temperature range
-20
125
°C
V
RAD
Output voltage
4.4
4.5
4.6
V
I
RAD
Output current
30
mA
I
QQ
Quiescent current
138
162
μ
A
V
DC
Line regulation
V
IN7
from 4.75V to 5.5V,
I
RAD
= 30 mA
3
mV
V
TRAN
Transient line regulation
V
IN7
from 4.75V to 5.5V,
I
RAD
= 30 mA,
rise time = fall time = 5
μ
s
35
mV
V
DC
Load regulation
10% to 90% of max I
RAD
3
mV
V
TRAN
Transient load regulation
10% to 90% of max I
RAD
,
rise time = fall time = 5
μ
s
17
mV
PSRR
Power supply rejection ratio
V
IN7
= 4.75V
@ 100 Hz
-60
dB
@ 1 kHz
-50
@ 20 kHz
-20
@ 100 kHz
-20
V
IN7
= 5.1V
@ 100 Hz
-70
@ 1 kHz
-65
@ 20 kHz
-45
@ 100 kHz
-35
V
IN7
= 5.5V
@ 100 Hz
-65
@ 1 kHz
-60
@ 20 kHz
-50
@ 100 kHz
-40
