參數資料
型號： RE031
英文描述： RE031 [Updated 3/03. 10 Pages] A dual mode Low Drop Out (LDO) voltage regulator macrocell with a fixed 2.5V output voltage. rated for loads of up to 5 mA. A typical application is real-time clock. backup battery supply in mobile terminals.
中文描述： RE031 [更新3月3日。 10頁]雙模式的低壓差（LDO）穩壓器電壓固定的2.5V輸出電壓調節器宏單元。額定高達5毫安的負載。一個典型的應用是實時時鐘。在移動終端的備用電池供電。
文件頁數： 3/8頁
文件大?。?/td> 123K
代理商： RE031
3
RE031 2.5V 5 mA LDO Voltage Regulator
2707B–PMGMT–03/03
Absolute Maximum Ratings
*
V
IN
..........................................................-0.3V to 6.5V
Electrical Specifications
(1)
T
A
= -20
°
C to +85
°
C, supply voltage = 3V to 5.5V unless otherwise specified, output capacitance = 2.2 μF.
Note:
1. Obtained by considering the parasitics of a TFBGA100 Package.
*NOTICE:
Stresses beyond those listed under “Absolute Maxi-
mum Ratings” may cause permanent damage to the
device. This is a stress rating only and functional
operation of the device at these or other conditions
beyond those indicated in the operational sections of
this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may
affect device reliability.
Digital Signals.........................................-0.3V to 5.5V
Output Current..................................Internally Limited
Junction Temperature..........................-20
°
C to 150
°
C
Table 1.
Electrical Characteristics
Symbol
Parameter
Condition
Min
Typ
Max
Unit
V
SAUVC
Auxiliary Operating Supply Voltage
2.4
2.5
2.6
V
V
SAUV
Output Voltage
2.4
2.5
2.6
V
I
SAUV
Output Current
5
mA
I
QQ
V
DC
V
TRAN
Quiescent Current
10
μA
Line Regulation
I
SAUV
= 5 mA
12
mV
Transient Line Regulation
I
SAUV
= 5 mA
rise time = fall time = 5 μs
37
mV
V
DC
V
TRAN
Load Regulation
10% - 90% of max I
SAUV
10
mV
Transient Load Regulation
10% - 90% of max I
SAUV
rise time = fall time = 5 μs
5
mV
PSRR
Power Supply Rejection Ratio
at Full Load
V
BAT
= 3V
@100 Hz
-55
dB
@1 kHz
-35
dB
@20 kHz
-12
dB
@100 kHz
-12
dB
V
BAT
= 4.25V
@100 Hz
-50
dB
@1 kHz
-35
dB
@20 kHz
-13
dB
@100 kHz
-13
dB
V
BAT
= 5.5V
@100 Hz
-40
dB
@1 kHz
-35
dB
@20 kHz
-13
dB
@100 kHz
-10
dB
V
N
Output Noise
Bandwidth = 10 Hz to 100 kHz;
output current = 5 mA
1051
μ V
RMS
I
SD
Shut Down Current
1
μA
