參數資料
型號： RF2504
廠商： RF MICRO DEVICES INC
元件分類： 衰減器
英文描述： VCO/HIGH-ISOLATION BUFFER AMPLIFIER
中文描述： 700 MHz - 1500 MHz RF/MICROWAVE WIDE BAND LOW POWER AMPLIFIER
封裝： SOIC-8
文件頁數： 2/8頁
文件大?。?/td> 92K
代理商： RF2504
Preliminary
12-2
RF2504
Rev A2 010117
12
P
Absolute Maximum Ratings
Parameter
Supply Voltage
Power Down Voltage (V
PD
)
Operating Ambient Temperature
Storage Temperature
Rating
-0.5 to +5.8
-0.5 to +5.8
-40 to +85
-55 to +150
Unit
V
DC
V
DC
°C
°C
Parameter
Specification
Typ.
Unit
Condition
Min.
Max.
Overall
Operating Frequency
700 to 1500
MHz
915MHz Operation
T=25°C, V
CC
=2.7V, Z
LOAD
=50
,
V
PD
=2.7V
Output Power
2nd Harmonic
3rd Harmonic
Load Pulling
V
CC
Pushing
Phase Noise
-6
-8
-19
200
4.7
-104
dBm
dBc
dBc
kHz
MHz/V
dBc
Into 1.67VSWR Load
100kHz Offset. Better phase noise is achiev-
able at the expense of output power.
10kHz Offset
-83
dBc
Power Supply
Operating Voltage
2.2 to 5.0
V
DC
At 2.2V and -40°C, output power will be
reduced to typically -11dBm.
Supply Current
5.5
mA
Caution!
ESD sensitive device.
RF Micro Devices believes the furnished information is correct and accurate
at the time of this printing. However, RF Micro Devices reserves the right to
make changes to its products without notice. RF Micro Devices does not
assume responsibility for the use of the described product(s).
相關PDF資料
PDF描述
RF2506 VHF/UHF VCO/HIGH-ISOLATION BUFFER AMPLIFIER
RF2510 VHF/UHF TRANSMITTER
RF2512 UHF TRANSMITTER
RF2513 UHF TRANSMITTER
RF2514 VHF/UHF TRANSMITTER
相關代理商/技術參數
參數描述
RF2505-000 功能描述:可復位保險絲 RoHS:否 制造商:Bourns 電流額定值: 電阻:7.5 Ohms 最大直流電壓: 保持電流:0.1 A 安裝風格:SMD/SMT 端接類型:SMD/SMT 跳閘電流:0.6 A 引線間隔: 系列:MF-PSHT 工作溫度范圍:- 40 C to + 125 C
RF2506 制造商:RFMD 制造商全稱:RF Micro Devices 功能描述:VHF/UHF VCO/HIGH-ISOLATION BUFFER AMPLIFIER
RF2509-000 功能描述:可復位保險絲 RoHS:否 制造商:Bourns 電流額定值: 電阻:7.5 Ohms 最大直流電壓: 保持電流:0.1 A 安裝風格:SMD/SMT 端接類型:SMD/SMT 跳閘電流:0.6 A 引線間隔: 系列:MF-PSHT 工作溫度范圍:- 40 C to + 125 C
RF250AA12 制造商:Johanson Manufacturing 功能描述:RESISTOR THICK FILM FLANGED 100OHM 制造商:Johanson Manufacturing 功能描述:RESISTOR THICK FILM FLANGED, 100OHM 制造商:Johanson Manufacturing 功能描述:RESISTOR THICK FILM FLANGED, 100 OHM; Resistance:100ohm; Power Rating:250W; Frequency Max:6GHz; Resistance Tolerance: 5%; Temperature Coefficient: 100ppm/C; Frequency Range:0Hz to 6GHz; Operating Temperature Max:100C; Series:RF ;RoHS Compliant: Yes 制造商:Johanson Manufacturing 功能描述:RF RESISTOR
RF250AB12 制造商:Johanson Manufacturing 功能描述:RESISTOR THICK FILM FLANGED 50OHM 制造商:Johanson Manufacturing 功能描述:RESISTOR, THICK FILM FLANGED, 50OHM 制造商:Johanson Manufacturing 功能描述:RESISTOR, THICK FILM FLANGED, 50 OHM; Resistance:50ohm; Power Rating:250W; Frequency Max:1.5GHz; Resistance Tolerance: 5%; Temperature Coefficient: 100ppm/C; Frequency Range:0Hz to 1.5GHz; Operating Temperature Max:100C ;RoHS Compliant: Yes 制造商:Johanson Manufacturing 功能描述:RF RESISTOR
