www.ti.com
FEATURES
Best in Class Performance Through Patented
HDX Technology
RS232 Interface
Multi Purpose I/Os
Proven in Harsh Industrial Environments
Easy to Install and Use
APPLICATIONS
Access Control
Vehicle Identification
Container Tracking
Asset Management
Waste Management
DESCRIPTION
The Texas Instruments' low-frequency (LF) reader provides all the functionality required to communicate with
Texas Instruments 134.2 kHz LF transponders which are available in a variety of form factors.
RI-CTL-MB2A, RI-CTL-MB6A
SCBS846–JANUARY 2003
SERIES 2000 CONTROL MODULE
The Series 2000 Control Module (CTL) is the interface between a TI-RFid Radio Frequency Module and a
controlling host. The CTL controls the transmitting and receiving functions of an RFM module such as the
RI-RFM-003B, RI-RFM-007B or RI-RFM-008B according to the commands from the host to send signals to and
receive data from a TI-RFid LF transponder. It converts the received RF signals to the transponder's
identification number, checks the validity and handles the conversion to the standard RS232 (RI-CTL-MB2A) or
the RS422/485 (RI-CTL-MB6A) serial interface protocol.
The CTL in combination with an RFM module is well suited for usage in a broad range of applications including,
but not limited to, access control, vehicle identification, container tracking, asset management and waste
management applications
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
TI-RFid is a trademark of Texas Instruments.
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
Copyright 2003, Texas Instruments Incorporated
