RP500X
PIN DESCRIPTIONS
3
WLCSP-6 / SOT-23-6W
Pin No.
1
2
3
4
5
6
Symbol
V
OUT
PGND
L
X
V
IN
AGND
CE
Pin Description
Output
Ground
Lx Switching
Voltage Supply
Ground
Chip Enable (High Active)
PLP-1820-6
Pin No.
Symbol
Pin Description
1
CE
Chip Enable (High Active)
2
AGND
Ground
3
V
IN
Voltage Supply
4
L
X
Lx Switching
5
PGND
Ground
6
V
OUT
Output
ABSOLUTE MAXIMUM RATINGS
Item
Symbol
V
IN
V
LX
V
CE
V
OUT
I
LX
P
D
Rating
6.5
Unit
V
V
V
V
Vin Supply Voltage
Lx Pin Voltage
CE Pin Input Voltage
Vout Pin Voltage
Lx Pin Output Current
Power Dissipation
-0.3 to V
IN
+0.3
-0.3 to V
IN
+0.3
-0.3 to V
IN
+0.3
800
PLP
SOT
WLCSP
-40 to 85
-55 to 125
mA
mW
880
430
T.B.D.
Operating Temp. Range
Storage Temp. Range
T
opt
T
stg
°
C
°
C
