RF AMP & SERVO SIGNAL PROCESSOR
S1L9226X
5
PRELIMINARY
INTRODUCTION
As a pre-signal & servo signal processor for the DISC-MAN, S1L9226X is a
low voltage, low consumption current IC that can read CD-RW, and CD-R
discs and can be applied to various products, such as the CDP/VCD/CD-
MP3 for the DISC-MAN. It is a hard-wired free-adjustment servo, which
automatically controlled the control point of the pre-signal portion.
FEATURES
RF amplifier (CD, CD-R, CD-RW applicable)
Gain setting & monitoring for the CD-R, CD-RW DISC
RFAMP offset adjustment
Focus error amp & Febias adjustment
Tracking error amp & balance, gain adjustment
FOK, defect, mirror detect
Center voltage amplifier
APC (Automatic Power Control)
RF AGC & EQ control (AGC Level Control Compatible)
Enhanced EFM slice (Double Asymmetry Method)
Focus servo loop & offset adjustment
Tracking servo loop & offset adjustment
Sled servo loop
Spindle servo loop
Auto-sequence
Fast search mode (1 - 36000 track jump)
Interruption countermeasure
Focus & Tracking servo muting controlled by EFM duty check
RF peaking prevention system by EFM duty check
Focus, tracking, spindle loop pole move option
Operating voltage 2.7V
3.3V
Power saving mode
<Notice> LPC Control used by side beam signal, it related to pick-up assurance.
When used pick-up, the specification is present extra.
ORDERING INFORMATION
Device
Package
Supply Voltage
Operating Temperature
S1L9226X01
Q0R0
48-LQFP-0707
2.7V
3.3V
-20
°
C
+75
°
C
48-LQFP-0707
