XE167x
XE166 Family Derivatives
Functional Description
Data Sheet
37
V2.1, 2008-08
3.1
Memory Subsystem and Organization
The memory space of the XE167 is configured in the von Neumann architecture. In this
architecture all internal and external resources, including code memory, data memory,
registers and I/O ports, are organized in the same linear address space.
Table 5
XE167 Memory Map
Address Area
Start Loc. End Loc.
Area Size1)
1) The areas marked with “<” are slightly smaller than indicated. See column “Notes”.
Notes
IMB register space
FF’FF00H
FF’FFFFH
256 Bytes
–
Reserved (Access trap) F0’0000H
FF’FEFFH <1 Mbyte
Minus IMB registers
Reserved for EPSRAM E9’0000H
EF’FFFFH 448 Kbytes
Mirrors EPSRAM
Emulated PSRAM
E8’0000H
E8’FFFFH 64 Kbytes
Flash timing
Reserved for PSRAM
E1’0000H
E7’FFFFH 448 Kbytes
Mirrors PSRAM
Program SRAM
E0’0000H
E0’FFFFH
64 Kbytes
Maximum speed
Reserved for pr. mem.
CC’0000H
DF’FFFFH <1.25 Mbytes –
Program Flash 2
C8’0000H
CB’FFFFH 256 Kbytes
–
Program Flash 1
C4’0000H
C7’FFFFH 256 Kbytes
–
Program Flash 0
C0’0000H
C3’FFFFH 256 Kbytes
2)
2) The uppermost 4-Kbyte sector of the first Flash segment is reserved for internal use (C0’F000H to C0’FFFFH).
External memory area
40’0000H
BF’FFFFH 8 Mbytes
–
Available Ext. IO area3)
3) Several pipeline optimizations are not active within the external IO area. This is necessary to control external
peripherals properly.
20’5800H
3F’FFFFH
< 2 Mbytes
Minus USIC/CAN
USIC registers
20’4000H
20’57FFH
6 Kbytes
Accessed via EBC
MultiCAN registers
20’0000H
20’3FFFH
16 Kbytes
Accessed via EBC
External memory area
01’0000H
1F’FFFFH
< 2 Mbytes
Minus segment 0
SFR area
00’FE00H
00’FFFFH
0.5 Kbyte
–
Dual-Port RAM
00’F600H
00’FDFFH 2 Kbytes
–
Reserved for DPRAM
00’F200H
00’F5FFH
1 Kbyte
–
ESFR area
00’F000H
00’F1FFH
0.5 Kbyte
–
XSFR area
00’E000H
00’EFFFH
4 Kbytes
–
Data SRAM
00’A000H
00’DFFFH
16 Kbytes
–
Reserved for DSRAM
00’8000H
00’9FFFH
8 Kbytes
–
External memory area
00’0000H
00’7FFFH
32 Kbytes
–
