型號: SAK-XE160FU-4F40R
廠商: INFINEON TECHNOLOGIES AG
元件分類: 微控制器/微處理器
英文描述: 16-BIT, FLASH, 40 MHz, RISC MICROCONTROLLER, PDSO38
封裝: 0.50 MM PITCH, GREEN, PLASTIC, TSSOP-38
文件頁數: 80/101頁
文件大小: 2936K
代理商: SAK-XE160FU-4F40R
XE160FU
XE166 Family / Compact Line
Summary of Features
PRELIMINARY
Data Sheet
4
V1.0, 2010-12
On-Chip Peripheral Modules
– Synchronizable 12-bit A/D Converter with up to 8 channels,
conversion time below 1
μs, optional data preprocessing (data reduction, range
check), broken wire detection
– 16-channel general purpose capture/compare unit (CC2)
– Capture/compare unit for flexible PWM signal generation (CCU60)
– Multi-functional general purpose timer unit with 5 timers
– Up to 2 serial interface channels to be used as UART, LIN, high-speed
synchronous channel (SPI/QSPI), IIC bus interface (10-bit addressing, 400 kbit/s),
IIS interface
– On-chip system timer and on-chip real time clock
Single power supply from 3.0 V to 5.5 V
Power reduction and wake-up modes with flexible power management
Programmable window watchdog timer and oscillator watchdog
Up to 28 general purpose I/O lines
On-chip bootstrap loaders
Supported by a full range of development tools including C compilers, macro-
assembler packages, emulators, evaluation boards, HLL debuggers, simulators,
logic analyzer disassemblers, programming boards
On-chip debug support via Device Access Port (DAP), Single-Pin DAP (SPD) or
JTAG interface
38-pin Green TSSOP package, 0.5 mm (10.7 mil) pitch
Ordering Information
The ordering code for an Infineon microcontroller provides an exact reference to a
specific product. This ordering code identifies:
the function set of the corresponding product type
the temperature range1):
– SAF-…: -40°C to 85°C
– SAK-…: -40°C to 125°C
the package and the type of delivery.
For ordering codes for the XE160FU please contact your sales representative or local
distributor.
1) Not all derivatives are offered in all temperature ranges.
