SB0203EJ
No.8169-1/3
Applications
High frequency rectification (switching regulators, converters, choppers).
Features
Low switching noise.
Low leakage current and high reliability due to highly reliable planar structure.
Ultraminiature (1608 size) and thin (0.6mm) leadless package.
Specifications
Absolute Maximum Ratings at Ta=25
°C
Parameter
Symbol
Conditions
Ratings
Unit
Repetitive Peak Reverse Voltage
VRRM
30
V
Nonrepetitive Peak Reverse Surge Voltage
VRSM
35
V
Average Output Current
IO
200
mA
Surge Forward Current
IFSM
50Hz sine wave, 1 cycle
2
A
Junction Temperature
Tj
--55 to +125
°C
Storage Temperature
Tstg
--55 to +125
°C
Electrical Characteristics at Ta=25
°C
Ratings
Parameter
Symbol
Conditions
min
typ
max
Unit
Reverse Voltage
VR
IR=50A30
V
Forward Voltage
VF
IF=200mA
0.55
V
Reverse Current
IR
VR=15V
5
A
Reverse Recovery Time
trr
IF=IR=10mA, See specified Test Circuit.
10
ns
Interterminal Capacitance
C
VR=10V, f=1MHz
7.7
pF
Thermal Resistance
Rth(j-a)
Mounted on a ceramic board (250mm2!0.8mm)
220
°C / W
Marking : DA
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
Ordering number : ENN8169
D2404SB TS IM TB-00001043
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft's
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SB0203EJ
Schottky Barrier Diode
30V, 200mA Rectifier
