參數資料
| 型號： | SCE028XD3SU2B |
| 廠商： | Mallory Sonalert Products Inc |
| 文件頁數： | 1/1頁 |
| 文件大?。?/td> | 0K |
| 描述： | BUZZ VDC 2.9KHZ FAST SPEED UP |
| 3D 型號： | SCES.igs SCES.stp |
| 標準包裝： | 1 |
| 系列： | Sonalert® |
| 驅動器電路： | 指示燈，內部驅動 |
| 技術： | 壓電 |
| 輸入類型： | DC |
| 電壓范圍： | 16 ~ 28V |
| 頻率： | 2.9kHz |
| 工作模式： | 加速，快速 |
| 聲壓級： | 95dB @ 16V，61cm |
| 電流 - 電源： | 40mA |
| 可清洗： | 無 |
| 安裝類型： | 面板安裝 |
| 端子： | 端接塊 |
| 尺寸/尺寸： | 圓形 - 42.85mm 直徑 x 38.39mm H |
| 包裝： | 散裝 |
| 工作溫度： | -40°C ~ 85°C |
Part #:
Revision:
Sound Level Category
Specifications:
SCE028XD3SU2B
B
Mallory Sonalert Products,Inc.
Sales Outline Drawing
Extra Loud
Sound Level Category
Mode of Operation
Housing Material
Storage Temperature
Fast Speed Up @ 0.5 -8 PPS in 30 Seconds
2900 ± 500 Hz
Extra Loud
16 to 28 VDC
Voltage Rating
6/6 Nylon, Color: Black
Frequency
Loudness @ 2 FT
Current Draw
95 to 105 dB(A) Typ.
40mA MAX
-40° to +85° C
UL R
i
d
gp
Operating Temperature
Panel Mounting
NEMA 3R,4X, & 12
Weight (Typical)
-40° to +85° C
cUL Recognition
cUL Recognized
Recommended hole size is 1.25"(31.75mm). Thread front will fit standard 30mm(1.181") hole.
Knurled Nut
Used to attach part to panel. The max recommended torque is 10 in-lbs.
1.6 oz (45g)
Approved with use of ACC03.
Please contact factory.
Options
cUL Recognized
Dimensions:
ROHS Compliant
Inches (mm)
T
R
Solutions
L E
A
N
O
Made in U.S.A.
S
T
R
Solutions
L E
A
N
O
Made in U.S.A.
S
T
R
Solutions
L E
A
N
O
Made in U.S.A.
S
T
R
Solutions
L E
A
N
O
Made in U.S.A.
S
4411 South High School Road, Indianapolis, Indiana 46241 U.S.A Phone: (317) 612-1000 Fax: (317) 612-1010
www.mallory-sonalert.com
T
R
Solutions
L E
A
N
O
Made in U.S.A.
S
