July 2002
Specifications subject to change without notice,contact your sales representatives for the most recent information.
14/28
PID 5964 07/02
SyncMOS Technologies Inc. SM5964
To reset the WDT is done by setting 1 to the CLEAR bit of WDTC. This will clear the content of the 16-bit counter and let
the counter re-start to count from the beginning.
4.1 Watch Dog Timer Registers: WDTC and SCONF
Watch Dog Timer Register- WDT Control Register (WDTC, $9F)
WDTE: Watch Dog Timer enable bit
CLEAR: Watch Dog Timer counter clear bit
PS[2:0]: clock source divider bit
Watch Dog Timer Register - System Control Register (SCONF, $BF)
The bit 7 (WDR) of SCONF is Watch Dog Timer Reset bit. It will be set to 1 when reset signal generated by WDT
overflow. User should check WDR bit whenever unpredicted reset happened
bit-7
bit-0
Read:
Write:
Reset value:
WDTE
Unused
CLEAR
Unused
Unused
PS2
PS1
PS0
0
*
0
*
*
0
0
0
PS [2:0]
Divider (OSC in)
Time Period (ms) @40MHZ
000
8
13.1
001
16
26.21
010
32
52.42
011
64
104.8
100
128
209.71
101
256
419.43
110
512
838.86
111
1024
1677.72
bit-7
bit-0
Read:
Write:
Reset value:
WDR
Unused
Unused
Unused
Unused
ISPE
OME
ALEI
0
*
*
*
*
0
1
0
