SM77H Series 1.8V
CMOS Clock Oscillators
April 2007
Pletronics’ SM77H Series is a quartz crystal
controlled precision square wave generator with a
CMOS output.
The package is designed for high density surface
mount designs.
This is a low cost mass produced oscillator.
Tape and Reel or cut tape packaging is available.
1 to 70 MHz
5 x 7 mm LCC Ceramic Package
Enable/Disable
Disable function includes low standby power
mode
Low Jitter
Pletronics Inc. certifies this device is in accordance with the
RoHS 6/6 (2002/95/EC) and WEEE (2002/96/EC) directives.
Pletronics Inc. guarantees the device does not contain the following:
Cadmium, Hexavalent Chromium, Lead, Mercury, PBB’s, PBDE’s
Weight of the Device: 0.17 grams
Moisture Sensitivity Level: 1 As defined in J-STD-020C
Second Level Interconnect code: e4
Absolute Maximum Ratings:
Parameter
Unit
V
CC
Supply Voltage
-0.5V to +7.0V
Vi Input Voltage
-0.5V to V
CC
+ 0.5V
Vo Output Voltage
-0.5V to V
CC
+ 0.5V
Io Output Current
+25 mA to -25 mA
Thermal Characteristics
The maximum die or junction temperature is 155
o
C
The thermal resistance junction to board is 30 to 50
o
C/Watt depending on the solder pads, ground plane
and construction of the PCB.
