KPC-0008-000
2
SPC814
Absolute maximum ratings
(Ta= 25)
Characteristic
Symbol
Ratings
Unit
Continuous Forward Current
I
F
50
mA
IRED
Power Dissipation
P
D
70
mW
Collector-Emitter Voltage
V
CEO
35
V
Emitter-Collector Voltage
V
ECO
6
V
Collector Current
I
C
50
mA
Detector
Power Dissipation
P
D
150
mW
Operating Temperature
T
opr
-30~ 100
Storage Temperature
T
stg
-55~ 125
Soldering Temperature
T
sol
260
within 10 seconds
Coupler
*1
Isolation Voltage
V
iso
2,500
V
rms
*1.Measured at RH = 40 ~ 60% for 1 min
Electrical Characteristics
Parameter
Symbol
Test Condition
Min.
Typ.
Max.
Unit
Forward Current
V
F
I
F
= 10mA
-
1.15
1.3
V
IRED
Capacitance
C
T
V= 0V,f= 1MHz
-
30
-
pF
Collector-Emitter Breakdown Voltage
BV
CEO
I
C
= 0.5mA
35
-
-
V
Emitter-Collector Breakdown Voltage
BV
ECO
I
E
= 10uA
6
-
-
V
Collector Dark Current
I
CEO
I
F
= 0mA,V
CE
= 10V
-
-
100
nA
Detector
Capacitance
C
CE
V
CE
= 0,f= 1MHz
-
10
-
pF
Current Transfer Ratio
CTR
I
F
= 5mA,V
CE
= 5V
50
-
600
%
Collector-Emitter Saturation Voltage
V
CE(sat)
I
F
= 5mA,I
C
= 1mA
-
-
0.4
V
Input-Output Capacitance
C
I-O
V= 0V,f= 1MHz
DC 500V
40~ 60% RH
-
0.8
-
pF
Coupler
Isolation Resistance
R
iso
-
10
11
Rise Time
t
r
-
4
-
Switching Time
Fall Time
t
f
V
CC
= 5V,R
L
= 100
I
C
= 2mA
-
4
-
usec
