參數資料
| 型號： | SPT7866SIR |
| 廠商： | SIGNAL PROCESSING TECHNOLOGIES |
| 元件分類： | ADC |
| 英文描述： | 1-CH 10-BIT PROPRIETARY METHOD ADC, PARALLEL ACCESS, PDSO28 |
| 封裝： | SSOP-28 |
| 文件頁數： | 2/5頁 |
| 文件大小： | 40K |
| 代理商： | SPT7866SIR |
SPT
2
8/15/00
SPT7866
ABSOLUTE MAXIMUM RATINGS (Beyond which damage may occur)1 25 °C
Supply Voltages
VDD ....................................................................... TBD
OVDD ..................................................................... TBD
Input Voltages
Analog Input .......................................................... TBD
CLK Input .............................................................. TBD
Note: 1. Operation at any Absolute Maximum Rating is not implied. See Electrical Specifications for proper nominal applied conditions in typical
applications.
Output
Digital Outputs ....................................................... TBD
Temperature
Operating Temperature ........................... –40 to +85 °C
Storage Temperature ............................ –65 to +150 °C
ELECTRICAL SPECIFICATIONS
TA=TMIN to TMAX, VDD=+5.0 V, S=60 MSPS, VRHS=3.0 V, VRLS=2.0 V, unless otherwise specified.
TEST
SPT7866
PARAMETERS
CONDITIONS
LEVEL
MIN
TYP
MAX
UNITS
Resolution
10
Bits
DC Accuracy
Differential Linearity Error (DLE)
@ +25 °C
V
±0.5
LSB
full temperature
±0.75
LSB
Integral Linearity Error (ILE)
@ +25 °C
V
±0.75
LSB
full temperature
±1.0
LSB
No Missing Codes
VI
Guaranteed
Analog Input
Input Voltage Range (Differential)
V
±1
V
Input Common Mode
V
2.5
V
Input Capacitance
V
2
pF
Common Mode Rejection Ratio (CMRR)
TBD
Timing Characteristics
Conversion Rate
VI
60
MSPS
Pipeline Delay (Latency)
IV
7
clocks
Output Delay (tD)
IV
TBD
ns
Aperture Delay Time
V
TBD
ns
Aperture Jitter Time
V
TBD
ps (rms)
Dynamic Performance
Effective Number of Bits (ENOB)
IN = 10 MHz, CLK = 60 MSPS
25 °C
I
9.2
9.3
Bits
–40 °C to +85 °C
IV
9.0
9.1
Bits
Signal-to-Noise Ratio (SNR)
IN = 10 MHz, CLK = 60 MSPS
25 °C
I
58
59
dB
–40 °C to +85 °C
IV
57
58
dB
Total Harmonic Distortion (THD)
IN = 10 MHz, CLK = 60 MSPS
25 °C
I
–70
–68
dB
–40 °C to +85 °C
IV
–69
–67
dB
Signal-to-Noise and Distortion (SINAD)
IN = 10 MHz, CLK = 60 MSPS
25 °C
I
57
58
dB
–40 °C to +85 °C
IV
56
57
dB
Spurious Free Dynamic Range (SFDR)
IN = 10 MHz, CLK = 60 MSPS
25 °C
I
70
74
dB
–40 °C to +85 °C
IV
68
72
dB
