1995 Mar 21
2
Philips Semiconductors
Product specification
Low power VHF, UHF and hyperband
mixer/oscillator for TV and VCR 3-band tuners
TDA5731M
FEATURES
Balanced mixer with a common emitter input for band A
(single input)
2-pin oscillator for bands A and B
3-pin oscillator for band C
Balanced mixer with a common base input for band B
and C (balanced input)
Local oscillator buffer output for external synthesizer
SAW filter preamplifier with a low output impedance to
drive the SAW filter directly
Electronic band switch.
APPLICATIONS
3-band TV tuners
3-band TV front-ends
3-band VCR tuners
3-band VCR front-ends.
GENERAL DESCRIPTION
The TDA5731M is a monolithic integrated circuit that
performs the band A, band B and band C mixer/oscillator
functions in TV and VCR tuners. This low power
mixer/oscillator circuit requires a power supply of 5 V and
is available in a very small package outline. This device
gives the designer the capability to design an economical
and physically small 3-band tuner. The tuner development
time can be drastically reduced by using this device.
In addition, when hyperband is not required, the
TDA5731M may be used in a VHF/UHF tuner with an
appropriate tuned circuit for VHFl and VHFlll in band A and
the tuned circuit of band C for UHF.
QUICK REFERENCE DATA
ORDERING INFORMATION
SYMBOL
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
UNIT
V
P
I
P
f
R
supply voltage
supply current
frequency range
42
160
430
5.0
36
7.5
8.0
9.0
66
66
66
23
34
33
180
470
860
V
mA
MHz
MHz
MHz
dB
dB
dB
dB
dB
dB
dB
dB
dB
band A
band B
band C
band A
band B
band C
band A
band B
band C
band A
band B
band C
N
noise figure
IP
intermodulation
G
v
voltage gain
TYPE
NUMBER
PACKAGE
NAME
DESCRIPTION
VERSION
TDA5731M
SSOP20
plastic shrink small outline package; 20 leads; body width 4.4 mm
SOT266-1
