| 型號： | TDA8417 |
| 廠商： | NXP SEMICONDUCTORS |
| 元件分類： | 消費家電 |
| 英文描述： | TV and VTR stereo/dual sound processor with integrated filters and IIC-bus control(帶IIC總線控制和集成濾波器的的 TV和VTR立體聲/雙聲道處理器) |
| 中文描述： | SPECIALTY CONSUMER CIRCUIT, PDIP20 |
| 封裝： | 0.300 INCH, PLASTIC, EIAJ, SC-603, SOT-146-1, DIP-20 |
| 文件頁數： | 7/20頁 |
| 文件大小： | 130K |
| 代理商： | TDA8417 |
September 1989
7
Philips Semiconductors
Preliminary specification
TV and VTR stereo/dual sound processor
with integrated filters and I
2
C-bus control
TDA8417
Power-on reset
The following actions are carried out by the internal power-on reset when it is active:
The AF outputs are muted
The identification circuit is deactivated (mono)
The control ports (C1 and C2) are set LOW
The I
2
C-bus transceiver is initialized
When the power-on reset becomes passive the following occurs:
The AF outputs are kept in the mute state until the contents of the switch register are changed from (00) hex via the
I
2
C-bus
The identification circuit is activated
The control ports are LOW until the mute and control port register is changed (CR bits 10, 11, 20 and 21)
The I
2
C-bus transceiver is activated
