1997 Sep 12
2
Philips Semiconductors
Preliminary specification
Brushless DC motor drive circuit
TDF5242T
FEATURES
Full-wave commutation without position sensors
Built-in start-up circuitry
Six outputs that can drive three external transistor pairs:
– output current 0.2 A (typ.)
– low saturation voltage
– built-in current limiter
Thermal protection
Tacho output without extra sensor
Transconductance amplifier for an external control
transistor
Brake control input
Direction control input.
APPLICATIONS
High-power applications, for instance:
– high-end hard disk drives
– automotive applications.
GENERAL DESCRIPTION
The TDF5242T is a bipolar integrated circuit for driving
3-phase brushless DC motors in full-wave mode.
The device functions sensorless, thus saving 3 hall-effect
sensors, using the back-EMF (Electro Motive Force)
sensing technique to sense the rotor position. It includes
6 pre-drivers able to control external FETs (Field Effect
Transistors) or bipolar transistors. It offers brake and
direction control. It is ideally suited for high-power
applications such as high-end hard disk drives and
automotive applications.
QUICK REFERENCE DATA
Measured over full voltage and temperature range.
Note
1.
An unstabilized supply can be used.
ORDERING INFORMATION
SYMBOL
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
UNIT
V
P
V
VMOT
supply voltage
input voltage to the output
driver stages
driver output voltage
note 1
4
3
18
18
V
V
V
O
I
O
= 100 mA; lower transistor
I
O
= 100 mA; upper transistor
V
VMOT
= 14.5 V; R
O
= 47
1.05
150
200
0.35
250
V
V
mA
I
LIM
current limiting
TYPE
NUMBER
PACKAGE
NUMBER
DESCRIPTION
VERSION
TDF5242T
SO28
plastic small outline package; 28 leads; body width 7.5 mm
SOT136-1
