TFP420
PanelBus
DIGITAL TRANSMITTER
SLDS123A – MARCH 2000 – REVISED JUNE 2000
16
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
register description (continued)
SYNC_CTRL0
Subaddress = 3D
Default = 0x03
7
6
5
4
3
2
1
0
RSVD
HS_COM
VSEN
HSEN
TYSEN
THSEN
DVI HSYNC enable
0
HSYNC is transmitted as 0
1(*)
HSYNC is transmitted as received from the video port
TVSEN
DVI VSYNC enable
0
VSYNC is transmitted as 0
1(*)
VSYNC is transmitted as received from the video port
HSEN
HS enable
0(*)
HS is in inactive state (LOW)
1
HS outputs digital horizontal/composite sync
VSEN
VS enable
0(*)
VS is in inactive state (LOW)
1
VS outputs digital vertical sync
HS_COM HS function select
0(*)
HS outputs horizontal sync
1
HS outputs composite sync
CON_STATUS
Subaddress = 3E
Read Only
7
6
5
4
3
2
1
0
RSVD
HPCON
RXCON
0
DVI receiver is not connected
1
DVI receiver is connected
HPCON
0
Hot plug is not connected
1
Hot plug is connected
INT_STATUS
Subaddress = 3F
Read Only
7
6
5
4
3
2
1
0
HPEVNT
RXEVNT
0
RXCON bit has not changed
1
RXCON bit has changed
HPEVNT
0
HPCON bit has not changed
1
HPCON bit has changed
To clear a bit, write 1 to the bit to clear. Writing 0 will not change the bit status.
INT_ENABLE
Subaddress = 40
Default = 0x00
7
6
5
4
3
2
1
0
hpen
rxen
RXEN
0(*)
RXEVNT interrupt disabled
1
RXEVNT interrupt enabled
HPEN
0(*)
HPEVNT interrupt disabled
1
HPEVNT interrupt enabled
