TLV1562
2.7 V TO 5.5 V, HIGH-SPEED LOW-POWER RECONFIGURABLE ANALOG-TO-DIGITAL
CONVERTER WITH 4-INPUT, DUAL S/H, PARALLEL INTERFACE, AND POWER DOWN
SLAS162 – SEPTEMBER 1998
3
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
description (continued)
The converter incorporates a pair of differential high-impedance reference inputs that facilitate ratiometric
conversion, scaling, and isolation of analog circuitry from logic and supply noise. Other features such as low
input capacitance (10 pF) and very wide input bandwidth (75 MHz) make this device a perfect digital signal
processing (DSP) companion for mobile communication applications. A switched-capacitor design allows
low-error conversion over the full operating free-air temperature range.
The features that make this device truly a DSP friendly converter include: 1) programmable continuous
conversion modes, 2) programmable 2s complement output code format, and 3) programmable resolution. The
TLV1562 is offered in both 28-pin TSSOP and SOIC packages. The TLV1562C is characterized for operation
from 0
°C to 70°C. The TLV1562I is characterized for operation over the full industrial temperature range of
–40
°C to 85°C.
AVAILABLE OPTIONS
PACKAGED DEVICE
TA
28-TSSOP
(25 MIL PITCH)
(PW)
28-SOIC
(50 MIL PITCH)
(DW)
0
°C to 70°C
TLV1562CPW
TLV1562CDW
–40
°C to 85°C
TLV1562IPW
TLV1562IDW
