A
6
.
3
V
I
)
D
1
(
I
out
in
SW
avg
=
×
-
=
(3)
F
SW
F
avg
D
V
)
D
1
(
I
V
I
P
×
-
×
=
×
=
(4)
Vout + 1.268 V
1 )
R1
R2
(5)
1
R
f
2
1
C
z
ff
×
p
×
=
(6)
SLVS771B – MAY 2007 – REVISED JUNE 2008 ............................................................................................................................................................... www.ti.com
Rectifier Diode Selection
To achieve high efficiency, a Schottky diode should be used. The reverse voltage rating should be higher than
the maximum output voltage of the converter. The current rating for the Schottky diode is calculated as the off
time of the converter times the typical switch current of the TPS65162:
where ISW=typical switch current of the TPS65162 (3.6 A)
A Schottky diode with 2-A maximum average rectified forward current rating is sufficient for most applications.
The Schottky rectifier must have adequate power dissipation. The dissipated power is the average rectified
forward current times the diode forward voltage.
where ISW=typical switch current of the TPS65162 (3.6 A)
Table 4. Rectifier Diode Selection (Boost Converter)
Iavg
Vr
Vforward
RθJA
SIZE
COMPONENT SUPPLIER
3 A
20 V
0.36 at 3 A
46°C/W
SMC
MBRS320, International Rectifier
2 A
20 V
0.44 V at 2 A
75°C/W
SMB
SL22, Vishay Semiconductor
2 A
20 V
0.5 at 2 A
75°C/W
SMB
SS22, Fairchild Semiconductor
Setting the Output Voltage and Selecting the Feedforward Capacitor
The output voltage is set by the external resistor divider and is calculated as:
Across the upper resistor a bypass capacitor is required to speed up the circuit during load transients. The
capacitor is caluculated as:
Depending on the inductor value, the zero frequency needs to be set. fz is 19 kHz for a 10 H inductor, and 9
kHz for a 22
H inductor. A value coming closest to the calculated value should be used.
Compensation (VC)
The regulator loop can be compensated by adjusting the external components connected to the VC pin. The VC
pin is the output of the internal transconductance error amplifier. A single capacitor connected to this pin sets the
low frequency gain. A 22-nF capacitor is usually sufficient for most applications.
20
Copyright 2007–2008, Texas Instruments Incorporated
Product Folder Link(s): TPS65162
