MOSEL V ITELIC
1
V16DJX432BLT/V16DJ432BLT
4M X 32 HIGH PERFORMANCE
EDO/FPM MEMORY MODULE
PRELIMINARY
V16DJX432BLT/V16DJ432BLT Rev. 0.1 February 1999
Features
I
V16DJX432BLT EDO
I
V16DJ432BLT FPM
I
Utilizes High Performance 1M x 8 CMOS DRAMs
I
Fast access times: 50 ns
I
Low power dissipation
I
CAS before RAS refresh, RAS only refresh, and
Hidden refresh capability
I
Standard 72-lead single-in-line module
I
Single 5 V
±
10% Power Supply
I
TTL Interface
Description
The V16DJX432BLT/V16DJ432BLT memory
Module is organized as 4,194,304 x 32 bits in a
72-lead single-in-line module. The 4M x 32 memory
module uses 16 Mosel-Vitelic 1M x 8 DRAMs. The
x32 modules are ideal for use in high performance
computer systems where increased memory
density and fast access times are required.
Device Usage Chart
Operating
Temperature
Range
Organization
Module Type
Access Time (ns)
Power
4M x 32
SIMM
50
Std
0
°
C to 70
°
C
V16DJX432BLT/V16DJ432BLT Pin Configuration
1
36
37
72
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
VSS
I/O1
I/O17
I/O2
I/O18
I/O3
I/O19
I/O4
I/O20
VCC
NC
A0
A1
A2
A3
A4
A5
A6
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
NC
I/O5
I/O21
I/O6
I/O22
I/O7
I/O23
I/O8
I/O24
A7
NC
VCC
A8
A9
RAS3
RAS2
NC
NC
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
NC
NC
VSS
CAS0
CAS2
CAS3
CAS1
RAS0
RAS1
NC
WE
NC
I/O9
I/O25
I/O10
I/O26
I/O11
I/O27
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
I/O12
I/O28
I/O13
I/O29
VCC
I/O30
I/O14
I/O31
I/O15
I/O32
I/O16
NC
PD1*
PD2*
PD3*
PD4*
NC
VSS
* Default Presence Detect is NC, Optional configurations are available.
Pin Names
Name
Description
A0–A10
Addresses
I/O1–I/O32
Data Inputs/Outputs
RAS0–RAS3
Row Address Strobes
CAS0–CAS3
Column Address Strobes
WE
Write Enable
PD1–PD4
Presence Detect
V
CC
Power Supply (5V)
V
SS
Ground
NC
No Connection
